思科 Catalyst 1300 系列交换机

Cisco Catalyst 1300 Series Switches
在线咨询采购

思科 Catalyst 1300 系列交换机

Cisco Catalyst ™ 1300 系列交换机是专为中小型企业设计和制造的经济实惠、易于使用的交换机。该交换机产品组合通过 Cisco ® Business Dashboard 和 Cisco Business 移动应用程序进行管理,提供简单可靠的体验。
Cisco-Switch-C1300
Cisco-Switch-C1300
Cisco-Switch-C1300
C1300-48P-4X | C1300-48P-4X-CNCisco-Switch-C1300
Cisco-Switch-C1300
Cisco-Switch-C1300
Cisco-Switch-C1300
Cisco-Switch-C1300
Cisco-Switch-C1300
Cisco-Switch-C1300

Cisco Catalyst 1300 Series Switches

Cisco Catalyst 1300 系列交换机是固定、托管、企业级千兆位以太网第 3 层交换机,专为中小型企业和分支机构而设计。这些简单、灵活且安全的交换机非常适合在配线间外部署

②采购咨询:186-1111-5727

思科 Catalyst 1300 系列交换机对比

简约与性能相得益彰,开始改造您的网络。 为您的混合分支机构获得企业级安全性、可靠性、连接性和强大功能。
10G 万兆上行系列
1G 千兆上行系列
48x 10/100/1000 PoE+ ports with 370W power budget,4x 10 Gigabit SFP+,Rack-mountableC1300-48P-4X-CN
  • 型号SKU:C1300-48P-4X-CN
  • 基础型号:C1300-48P-4X
  • 所属系列:Catalyst 1300系列
  • 下行端口:48个千兆POE+电口
  • 上行端口:4x 10G SFP+ 光口
  • 交换容量:176 Gbps
  • 转发速率:130.94 Mpps
  • POE预算:370W
  • 数据缓冲:3 MB
  • 硬件堆叠: 可8台
  • 默认电源: 内置
  • 风 扇: 1个
  • 设备尺寸:445 x 350 x 44 mm
  • 设备重量:5.43 kg
  • 查看详情 >
16x 10/100/1000 ports PoE+ ports with 120W power budget,4x 10 Gigabit SFP+,Rack-mountableC1300-16P-4X
  • 型号SKU:C1300-16P-4X-CN
  • 基础型号:C1300-16P-4X
  • 所属系列:Catalyst 1300系列
  • 下行端口:16个千兆POE+电口
  • 上行端口:4x 10G SFP+ 光口
  • 交换容量:112 Gbps
  • 转发速率:83.32 Mpps
  • POE预算:120W
  • 数据缓冲:1.5 MB
  • 硬件堆叠: 可8台
  • 默认电源: 内置
  • 风 扇: 无风扇
  • 设备尺寸:268 x 297 x 44 mm
  • 设备重量:2.49 kg
  • 查看详情 >
24x 10/100/1000 PoE+ ports with 195W power budget,4x 10 Gigabit SFP+,Rack-mountableC1300-24P-4X
  • 型号SKU:C1300-24P-4X-CN
  • 基础型号:C1300-24P-4X
  • 所属系列:Catalyst 1300系列
  • 下行端口:24个千兆POE+电口
  • 上行端口:4x 10G SFP+ 光口
  • 交换容量:128 Gbps
  • 转发速率:95.23 Mpps
  • POE预算:195W
  • 数据缓冲:1.5 MB
  • 硬件堆叠: 可8台
  • 默认电源: 内置
  • 风 扇: 无风扇
  • 设备尺寸:445 x 299 x 44 mm
  • 设备重量:3.68 kg
  • 查看详情 >
24x 10/100/1000 PoE+ ports with 370W power budget,4x 10 Gigabit SFP+,Rack-mountableC1300-24FP-4X
  • 型号SKU:C1300-24FP-4X-CN
  • 基础型号:C1300-24FP-4X
  • 所属系列:Catalyst 1300系列
  • 下行端口:24个千兆POE+电口
  • 上行端口:4x 10G SFP+ 光口
  • 交换容量:128 Gbps
  • 转发速率:95.23 Mpps
  • POE预算:370W
  • 数据缓冲:1.5 MB
  • 硬件堆叠: 可8台
  • 默认电源: 内置
  • 风 扇: 1个
  • 设备尺寸:445 x 345 x 44 mm
  • 设备重量:4.6 kg
  • 查看详情 >
24x 10/100/1000 ports,4x 10 Gigabit SFP+,Rack-mountableC1300-24T-4X
  • 型号SKU:C1300-24T-4X-CN
  • 基础型号:C1300-24T-4X
  • 所属系列:Catalyst 1300系列
  • 下行端口:24个千兆电口
  • 上行端口:4x 10G SFP+ 光口
  • 交换容量:128 Gbps
  • 转发速率:95.23 Mpps
  • POE预算:N/A
  • 数据缓冲:1.5 MB
  • 硬件堆叠: 可8台
  • 默认电源: 内置
  • 风 扇: 无风扇
  • 设备尺寸:445 x 240 x 44 mm
  • 设备重量:2.78 kg
  • 查看详情 >
48x 10/100/1000 ports,4x 10 Gigabit SFP+,Rack-mountableC1300-48T-4X
  • 型号SKU:C1300-48T-4X-CN
  • 基础型号:C1300-48T-4X
  • 所属系列:Catalyst 1300系列
  • 下行端口:48个千兆电口
  • 上行端口:4x 10G SFP+ 光口
  • 交换容量:176 Gbps
  • 转发速率:130.94 Mpps
  • POE预算:N/A
  • 数据缓冲:3 MB
  • 硬件堆叠: 可8台
  • 默认电源: 内置
  • 风 扇: 1个
  • 设备尺寸:445 x 288 x 44 mm
  • 设备重量:3.95 kg
  • 查看详情 >
8x 10/100/1000 ports,2x Gigabit copper/SFP combo ports,Rack-mountableC1300-8T-E-2G
  • 型号SKU:C1300-8T-E-2G-CN
  • 基础型号:C1300-8T-E-2G
  • 所属系列:Catalyst 1300系列
  • 下行端口:8个千兆电口
  • 上行端口:2x 1G copper/SFP 复用口
  • 交换容量:20 Gbps
  • 转发速率:14.88 Mpps
  • POE预算:N/A
  • 数据缓冲:1.5 MB
  • 硬件堆叠:可8台
  • 默认电源:外置 适配器
  • 风 扇:无风扇
  • 设备尺寸:268 x 185 x 44 mm
  • 设备重量:1.39 kg
  • 查看详情 >
8x 10/100/1000 PoE+ ports with 60W power budget,2x Gigabit copper/SFP combo ports,Rack-mountableC1300-8P-E-2G
  • 型号SKU:C1300-8P-E-2G-CN
  • 基础型号:C1300-8P-E-2G
  • 所属系列:Catalyst 1300系列
  • 下行端口:8个千兆POE+电口
  • 上行端口:2x 1G copper/SFP 复用口
  • 交换容量:20 Gbps
  • 转发速率:14.88 Mpps
  • POE预算:60W
  • 数据缓冲:1.5 MB
  • 硬件堆叠: 可8台
  • 默认电源:外置 适配器
  • 风 扇:无风扇
  • 设备尺寸:268 x 185 x 44 mm
  • 设备重量:1.53 kg
  • 查看详情 >
8x 10/100/1000 PoE+ ports with 120W power budget,2x Gigabit copper/SFP combo ports,Rack-mountableC1300-8FP-2G
  • 型号SKU:C1300-8FP-2G-CN
  • 基础型号:C1300-8FP-2G
  • 所属系列:Catalyst 1300系列
  • 下行端口:8个千兆POE+电口
  • 上行端口:2x 1G copper/SFP 复用口
  • 交换容量:20 Gbps
  • 转发速率:14.88 Mpps
  • POE预算:120W
  • 数据缓冲:1.5 MB
  • 硬件堆叠: 可8台
  • 默认电源: 内置
  • 风 扇:无风扇
  • 设备尺寸:268 x 272 x 44 mm
  • 设备重量:2.59 kg
  • 查看详情 >
16x 10/100/1000 ports,2x Gigabit SFP,Rack-mountableC1300-16T-2G
  • 型号SKU:C1300-16T-2G-CN
  • 基础型号:C1300-16T-2G
  • 所属系列:Catalyst 1300系列
  • 下行端口:16个千兆电口
  • 上行端口:2x 1G SFP 光口
  • 交换容量:36 Gbps
  • 转发速率:26.78 Mpps
  • POE预算:N/A
  • 数据缓冲:1.5 MB
  • 硬件堆叠: 可8台
  • 默认电源: 内置
  • 风 扇:无风扇
  • 设备尺寸:268 x 272 x 44 mm
  • 设备重量:1.78 kg
  • 查看详情 >
16x 10/100/1000 PoE+ ports with 120W power budget,2x Gigabit SFP,Rack-mountableC1300-16P-2G
  • 型号SKU:C1300-16P-2G-CN
  • 基础型号:C1300-16P-2G
  • 所属系列:Catalyst 1300系列
  • 下行端口:16个千兆POE+电口
  • 上行端口:2x 1G SFP 光口
  • 交换容量:36 Gbps
  • 转发速率:26.78 Mpps
  • POE预算:120W
  • 数据缓冲:1.5 MB
  • 硬件堆叠: 可8台
  • 默认电源: 内置
  • 风 扇:无风扇
  • 设备尺寸:268 x 297 x 44 mm
  • 设备重量:2.38 kg
  • 查看详情 >
16x 10/100/1000 PoE+ ports with 240W power budget,2x Gigabit SFP,Rack-mountableC1300-16FP-2G
  • 型号SKU:C1300-16FP-2G-CN
  • 基础型号:C1300-16FP-2G
  • 所属系列:Catalyst 1300系列
  • 下行端口:16个千兆POE+电口
  • 上行端口:2x 1G SFP 光口
  • 交换容量:36 Gbps
  • 转发速率:26.78 Mpps
  • POE预算:240W
  • 数据缓冲:1.5 MB
  • 硬件堆叠: 可8台
  • 默认电源: 内置
  • 风 扇:无风扇
  • 设备尺寸:268 x 308 x 44 mm
  • 设备重量:2.49 kg
  • 查看详情 >
24x 10/100/1000 ports,4x Gigabit SFP,Rack-mountableC1300-24T-4G
  • 型号SKU:C1300-24T-4G-CN
  • 基础型号:C1300-24T-4G
  • 所属系列:Catalyst 1300系列
  • 下行端口:24个千兆电口
  • 上行端口:4x 1G SFP 光口
  • 交换容量:56 Gbps
  • 转发速率:41.66 Mpps
  • POE预算:N/A
  • 数据缓冲:1.5 MB
  • 硬件堆叠: 可8台
  • 默认电源: 内置
  • 风 扇:无风扇
  • 设备尺寸:445 x 240 x 44 mm
  • 设备重量:2.63 kg
  • 查看详情 >
24x 10/100/1000 PoE+ ports with 195W power budget,4x Gigabit SFP,Rack-mountableC1300-24P-4G
  • 型号SKU:C1300-24P-4G-CN
  • 基础型号:C1300-24P-4G
  • 所属系列:Catalyst 1300系列
  • 下行端口:24个千兆POE+电口
  • 上行端口:4x 1G SFP 光口
  • 交换容量:56 Gbps
  • 转发速率:41.66 Mpps
  • POE预算:195W
  • 数据缓冲:1.5 MB
  • 硬件堆叠: 可8台
  • 默认电源: 内置
  • 风 扇:无风扇
  • 设备尺寸:445 x 240 x 44 mm
  • 设备重量:3.53 kg
  • 查看详情 >
24x 10/100/1000 PoE+ ports with 370W power budget,4x Gigabit SFP,Rack-mountableC1300-24FP-4G
  • 型号SKU:C1300-24FP-4G-CN
  • 基础型号:C1300-24FP-4G
  • 所属系列:Catalyst 1300系列
  • 下行端口:24个千兆POE+电口
  • 上行端口:4x 1G SFP 光口
  • 交换容量:56 Gbps
  • 转发速率:41.66 Mpps
  • POE预算:370W
  • 数据缓冲:1.5 MB
  • 硬件堆叠: 可8台
  • 默认电源: 内置
  • 风 扇: 1个
  • 设备尺寸:445 x 345 x 44 mm
  • 设备重量:4.6 kg
  • 查看详情 >
48x 10/100/1000 ports,4x Gigabit SFP,Rack-mountableC1300-48T-4G
  • 型号SKU:C1300-48T-4G-CN
  • 基础型号:C1300-48T-4G
  • 所属系列:Catalyst 1300系列
  • 下行端口:48个千兆电口
  • 上行端口:4x 1G SFP 光口
  • 交换容量:104 Gbps
  • 转发速率:77.38 Mpps
  • POE预算:N/A
  • 数据缓冲:3 MB
  • 硬件堆叠: 可8台
  • 默认电源: 内置
  • 风 扇: 1个
  • 设备尺寸:445 x 288 x 44 mm
  • 设备重量:3.95 kg
  • 在线咨询
48x 10/100/1000 PoE+ ports with 370W power budget,4x Gigabit SFP,Rack-mountableC1300-48P-4G
  • 型号SKU:C1300-48P-4G-CN
  • 基础型号:C1300-48P-4G
  • 所属系列:Catalyst 1300系列
  • 下行端口:48个千兆POE+电口
  • 上行端口:4x 1G SFP 光口
  • 交换容量:104 Gbps
  • 转发速率:77.38 Mpps
  • POE预算:370W
  • 数据缓冲:3 MB
  • 硬件堆叠: 可8台
  • 默认电源: 内置
  • 风 扇: 1个
  • 设备尺寸:445 x 350 x 44 mm
  • 设备重量:5.43 kg
  • 在线咨询
产品特点
产品规格
在售产品
选配信息

产品特点

 Cisco Catalyst 1300 Series Switches

任何中小型办公网络的关键构建块

从连接到云应用程序,网络在每个业务旅程中都发挥着至关重要的作用。可靠性、安全性和经济性仍然是首要考虑因素,而持续的管理和运营增加了复杂性,需要时间和资源。

Cisco Catalyst ™ 1300 系列交换机是专为中小型企业设计和制造的经济实惠、易于使用的交换机。该交换机产品组合通过 Cisco ® Business Dashboard 和 Cisco Business 移动应用程序进行管理,提供简单可靠的体验。

图1。思科业务仪表板和思科业务移动应用程序

思科 Catalyst 1300 系列交换机

Cisco Catalyst 1300 系列交换机是固定、托管、企业级千兆位以太网第 3 层交换机,专为中小型企业和分支机构而设计。这些简单、灵活且安全的交换机非常适合在配线间外部署。Catalyst 1300 系列在定制的 Linux 操作系统软件上运行,具有可简化网络设置的直观仪表板和可加速数字化转型的高级功能,同时普遍的安全性可保护关键业务交易。1300 系列交换机为中小型企业提供了经济性和功能的理想组合,并帮助您打造更高效、联系更紧密的员工队伍。当您的企业需要先进的网络功能和安全性来进行数字化转型,但价值仍然是首要考虑因素时

图 2.     思科 Catalyst 1300 系列交换机

商业应用

无论您需要基本的高性能网络来连接员工计算机,还是需要提供数据、语音和视频服务的解决方案,Cisco Catalyst 1300 系列交换机都能提供满足您需求的解决方案。可能的部署场景包括:

● 安全的办公室连接: 1300 系列交换机可以简单、安全地将小型办公室工作的员工相互连接起来,并与他们使用的所有服务器、打印机和其他网络设备连接。高性能和可靠的连接有助于加快文件传输和数据处理速度,提高网络正常运行时间,并让您的员工保持连接和生产力。

● 统一通信:作为托管网络解决方案,1300 系列交换机提供通过单个网络传送所有通信和数据所需的性能和高级流量处理智能。思科提供完整的 IP 电话和其他专为企业设计的统一通信产品组合。1300 系列交换机经过严格测试,有助于确保与这些产品及其他产品的轻松集成和完全兼容,从而提供完整的业务解决方案。

● 高度安全的访客连接: 1300 系列交换机可让您将高度安全的网络连接扩展到各种环境中的访客,例如酒店、办公室等候室或任何其他向非员工用户开放的区域。使用强大但易于配置的安全和流量分段功能,您可以将重要的业务流量与访客服务隔离,并保持访客网络会话彼此的私密性。

特点和优点

Cisco Catalyst 1300 系列交换机提供不断发展的企业所需的高级功能集以及高带宽应用和技术所需的高级功能集。它们提供以下好处。

易于管理和部署

1300 系列交换机旨在易于商业客户或为其服务的合作伙伴使用和管理,包括以下功能:

● Cisco Business Dashboard 旨在管理Cisco Business 交换机、Cisco Catalyst 1200 和1300 系列交换机、路由器和无线接入点。它简化了部署和管理业务网络的传统挑战,同时实现了网络部署、监控和生命周期管理的自动化。1300 系列交换机支持嵌入式探针以及直接管理,无需现场设置单独的硬件或虚拟机。设备加入向导简化了新设备到网络的设置和加入。欲了解更多信息,请访问https://www.cisco.com/go/cbd 。

● 思科网络即插即用解决方案提供简单、安全、统一和集成的产品,以简化新设备的部署或对现有网络的配置更新。该解决方案提供了一种统一的方法来配置思科路由器、交换机和无线设备,并提供近乎零接触的部署体验。

● 直观的用户界面减少了部署、故障排除和管理网络所需的时间,并允许您在不增加IT 人员数量的情况下支持复杂的功能。

● 这些交换机还支持文本视图,这是适合喜欢它的合作伙伴的完整命令行界面(CLI) 选项。

● 支持简单网络管理协议(SNMP),使您可以从网络管理站远程设置和管理交换机和其他思科设备,从而改进IT 工作流程和大规模配置。

● 这些交换机支持外部蓝牙适配器,该适配器可插入交换机上的 USB 端口,并允许与外部笔记本电脑和平板电脑进行基于蓝牙的 RF 连接(图 2)。笔记本电脑和平板电脑可以通过蓝牙使用 Telnet 或 Secure Shell (SSH) 客户端访问交换机 CLI。可以使用浏览器通过蓝牙访问 GUI。

高可靠性和弹性

在不断发展的企业中,每周 7 天、每天 24 小时的可用性至关重要,您需要提供业务连续性并确保员工始终可以访问他们所需的数据和资源。Cisco Catalyst 1300 系列交换机支持双映像,使您能够以最短的网络停机时间执行软件升级。

安全性强

Cisco Catalyst 1300 系列交换机提供保护业务数据并阻止未经授权的用户访问网络所需的高级安全功能:

● 支持高级网络安全应用程序(例如IEEE 802.1X)和端口安全性,严格限制对网络特定网段的访问。基于 Web 的身份验证提供了一致的界面来对所有类型的主机设备和操作系统进行身份验证,而无需在每个端点上部署 802.1X 客户端的复杂性。

● 先进的防御机制,包括动态地址解析协议(ARP) 检查、IP 源防护和动态主机配置协议(DHCP) 侦听,可检测并阻止蓄意的网络攻击。这些协议的组合也称为 IP/MAC/端口绑定 (IPMB)。

● IPv6 第一跳安全将高级威胁防护扩展到 IPv6。该全面的安全套件包括邻居发现 (ND) 检查、路由器通告 (RA) 防护、DHCPv6 防护和邻居绑定完整性检查,针对 IPv6 网络上的各种地址欺骗和中间人攻击提供无与伦比的保护。

以太网供电

Cisco Catalyst 1300 系列交换机最多可提供 48 个以太网供电 (PoE) 端口。此功能允许您通过单根以太网电缆连接网络端点并为其供电,从而简化了 IP 电话、无线和 IP 监控等先进技术部署。无需为 IP 电话或无线接入点安装单独的电源,您可以更快、更低成本地利用先进的通信技术。型号支持 802.3af PoE 和 802.3at PoE+。

IPv6支持

随着 IP 地址方案不断发展以适应越来越多的网络设备,Cisco Catalyst 1300 系列交换机可以支持向下一代网络的过渡。这些交换机继续支持上一代 IPv4,使您能够按照自己的节奏发展到新的 IPv6 标准,并帮助确保您当前的网络将来继续支持您的业务应用程序。

高级第 3 层流量管理

Cisco Catalyst 1300 系列交换机提供更先进的流量管理功能,帮助成长型企业更有效地组织其网络。例如,交换机提供动态第 3 层路由,允许您将网络分段为工作组并跨 VLAN 通信,而不会降低应用程序性能。

借助这些功能,您可以通过从路由器卸载内部流量处理任务并允许其主要管理外部流量和安全来提高网络效率。

真正的堆叠

Cisco Catalyst 1300 系列交换机为最多八台交换机提供真正的堆叠功能,允许您将堆叠中的所有交换机作为具有单个 IP 地址的单个单元进行配置、管理和故障排除。

除了管理平面之外,真正的堆栈还提供统一的数据和控制平面,从而提供灵活性、可扩展性和易用性,因为单元堆栈作为构成堆栈成员的所有端口的单个实体运行。此功能可以从根本上降低不断增长的网络环境中的复杂性,同时提高网络应用程序的弹性和可用性。真正的堆叠还通过跨堆叠服务质量 (QoS)、VLAN、链路聚合 (LAG) 和端口镜像等功能(集群交换机不支持这些功能)提供其他成本节约和管理优势。

紧凑型设计

Cisco Catalyst 1300 系列交换机时尚紧凑的设计提供了额外的部署灵活性,包括在零售店、开放式办公室和教室等场所的配线间外安装,而不会干扰环境。

电源效率

Cisco Catalyst 1300 系列交换机在所有型号中集成了多种节能功能,提供业界最广泛的节能交换产品组合。这些交换机旨在通过优化电力使用来节省能源,这有助于保护环境并降低能源成本。它们提供了环保的网络解决方案,且不影响性能。该开关具有以下特点:

● 支持节能以太网(IEEE 802.3az) 标准,该标准通过监控活动链路上的流量并在安静时段将链路置于睡眠状态来降低能耗。

● 当链路断开时自动关闭端口电源。

● 内置智能功能,可根据连接电缆的长度调整信号强度。

● 大多数型号采用无风扇设计,可降低功耗、提高可靠性并提供更安静的运行。

高枕无忧,投资保护

Cisco Catalyst 1300 系列交换机可提供您所期望的 Cisco 交换机的可靠性能和安心体验。它们经过严格测试,有助于确保最佳的网络正常运行时间并提供业务连续性。免费访问我们的小型企业支持中心一年,以获得持续支持和有限终身保修以及下一工作日 (NBD) 先行更换(如果有)有助于保持您的业务平稳运行。

Table 2 provides ordering information for the Cisco Catalyst 1300 Series Switches.

Table 2.        Ordering information

Model

Order product ID

Description

Gigabit Ethernet

C1300-8T-E-2G

C1300-8T-E-2G-xx

*  8x 10/100/1000 ports
*  2x Gigabit copper/SFP combo ports
*  Rack-mountable

C1300-8P-E-2G

C1300-8P-E-2G-xx

*  8x 10/100/1000 PoE+ ports with 60W power budget
*  2x Gigabit copper/SFP combo ports
*  Rack-mountable

C1300-8FP-2G

C1300-8FP-2G-xx

*  8x 10/100/1000 PoE+ ports with 120W power budget
*  2x Gigabit copper/SFP combo ports
*  Rack-mountable

C1300-16T-2G

C1300-16T-2G-xx

*  16x 10/100/1000 ports
*  2x Gigabit SFP
*  Rack-mountable

C1300-16P-2G

C1300-16P-2G-xx

*  16x 10/100/1000 PoE+ ports with 120W power budget
*  2x Gigabit SFP
*  Rack-mountable

C1300-16FP-2G

C1300-16FP-2G-xx

*  16x 10/100/1000 PoE+ ports with 240W power budget
*  2x Gigabit SFP
*  Rack-mountable

C1300-24T-4G

C1300-24T-4G-xx

*  24x 10/100/1000 ports
*  4x Gigabit SFP
*  Rack-mountable

C1300-24P-4G

C1300-24P-4G-xx

*  24x 10/100/1000 PoE+ ports with 195W power budget
*  4x Gigabit SFP
*  Rack-mountable

C1300-24FP-4G

C1300-24FP-4G-xx

*  24x 10/100/1000 PoE+ ports with 370W power budget
*  4x Gigabit SFP
*  Rack-mountable

C1300-48T-4G

C1300-48T-4G-xx

*  48x 10/100/1000 ports
*  4x Gigabit SFP
*  Rack-mountable

C1300-48P-4G

C1300-48P-4G-xx

*  48x 10/100/1000 PoE+ ports with 370W power budget
*  4x Gigabit SFP
*  Rack-mountable

Gigabit Ethernet with 10 Gigabit Ethernet uplinks

C1300-16P-4X

C1300-16P-4X-xx

*  16x 10/100/1000 ports PoE+ ports with 120W power budget
*  4x 10 Gigabit SFP+
*  Rack-mountable

C1300-24T-4X

C1300-24T-4X-xx

*  24x 10/100/1000 ports
*  4x 10 Gigabit SFP+
*  Rack-mountable

C1300-24P-4X

C1300-24P-4X-xx

*  24x 10/100/1000 PoE+ ports with 195W power budget
*  4x 10 Gigabit SFP+
*  Rack-mountable

C1300-24FP-4X

C1300-24FP-4X-xx

*  24x 10/100/1000 PoE+ ports with 370W power budget
*  4x 10 Gigabit SFP+
*  Rack-mountable

C1300-48T-4X

C1300-48T-4X-xx

*  48x 10/100/1000 ports
*  4x 10 Gigabit SFP+
*  Rack-mountable

C1300-48P-4X

C1300-48P-4X-xx

*  48x 10/100/1000 PoE+ ports with 370W power budget
*  4x 10 Gigabit SFP+
*  Rack-mountable

XX=NA, TW, JP, EU, UK, AU, AR, BR, CN, IN, KR (country-specific plug)

产品规格

Product specifications

Table 1 gives the product specifications for the Cisco Catalyst 1300 Series Switches.

Table 1.        Product specifications

Feature

Description

Performance

Switching capacity and forwarding rate

All switches are wire speed and nonblocking

Model

Capacity in Millions of Packets Per Second (mpps) (64-byte packets)

Switching capacity in Gigabits per second (Gbps)

C1300-8FP-2G

14.88

20.0

C1300-8T-E-2G

14.88

20.0

C1300-8P-E-2G

14.88

20.0

C1300-16T-2G

26.78

36.0

C1300-16P-2G

26.78

36.0

C1300-16FP-2G

26.78

36.0

C1300-24T-4G

41.66

56.0

C1300-24P-4G

41.66

56.0

C1300-24FP-4G

41.66

56.0

C1300-48T-4G

77.38

104.0

C1300-48P-4G

77.38

104.0

C1300-48FP-4G

77.38

104.0

C1300-16P-4X

83.32

112.0

C1300-24T-4X

95.23

128.0

C1300-24P-4X

95.23

128.0

C1300-24FP-4X

95.23

128.0

C1300-48T-4X

130.94

176.0

C1300-48P-4X

130.94

176.0

Layer 2 switching

Spanning Tree Protocol

Standard 802.1d Spanning Tree support

Fast convergence using 802.1w (Rapid Spanning Tree [RSTP]), enabled by default

Multiple Spanning Tree instances using 802.1s (MSTP); 8 instances are supported

Per-VLAN Spanning Tree Plus (PVST+) and Rapid PVST+ (RPVST+); 126 instances are supported

Port grouping/link aggregation

Support for IEEE 802.3ad Link Aggregation Control Protocol (LACP)

  Up to 8 groups
  Up to 8 ports per group with 16 candidate ports for each (dynamic) 802.3ad link aggregation

VLAN

Support for up to 4093 VLANs simultaneously

Port-based and 802.1Q tag-based VLANs, MAC-based VLAN, protocol-based VLAN, IP subnet-based VLAN

Management VLAN

Private VLAN with promiscuous, isolated, and community port

Private VLAN Edge (PVE), also known as protected ports, with multiple uplinks

Guest VLAN, unauthenticated VLAN

Dynamic VLAN assignment via RADIUS server along with 802.1X client authentication

Customer premises equipment (CPE) VLAN

Auto surveillance VLAN (ASV)

Voice VLAN

Voice traffic is automatically assigned to a voice-specific VLAN and treated with appropriate levels of QoS. Voice Services Discovery Protocol (VSDP) delivers networkwide zero-touch deployment of voice endpoints and call control devices

Multicast TV VLAN

Multicast TV VLAN allows the single multicast VLAN to be shared in the network while subscribers remain in separate VLANs. This feature is also known as Multicast VLAN Registration (MVR)

VLAN translation

Support for VLAN one-to-one mapping, in which customer VLANs (C-VLANs) on an edge interface are mapped to service provider VLANs (S-VLANs), and the original C-VLAN tags are replaced by the specified S-VLAN

Q-in-Q

VLANs transparently cross a service provider network while isolating traffic among customers

Selective Q-in-Q

Selective Q-in-Q is an enhancement to the basic Q-in-Q feature and provides, per edge interface, multiple mappings of different C-VLANs to separate S-VLANs

Selective Q-in-Q also allows configuring of the Ethertype (Tag Protocol Identifier [TPID]) of the S-VLAN tag

Layer 2 protocol tunneling over Q-in-Q is also supported

Generic VLAN Registration Protocol (GVRP)/Generic Attribute Registration Protocol (GARP)

GVRP and GARP enable automatic propagation and configuration of VLANs in a bridged domain

Unidirectional Link Detection (UDLD)

UDLD monitors physical connections to detect unidirectional links caused by incorrect wiring or cable/port faults to prevent forwarding loops and blackholing of traffic in switched networks

DHCP relay at Layer 2

Relay of DHCP traffic to a DHCP server in a different VLAN; works with DHCP Option 82

Internet Group Management Protocol (IGMP) versions 1, 2, and 3 snooping

IGMP limits bandwidth-intensive multicast traffic to only the requesters; it supports 2000 multicast groups (source-specific multicasting is also supported)

IGMP querier

IGMP querier is used to support a Layer 2 multicast domain of snooping switches in the absence of a multicast router

IGMP proxy

The IGMP proxy provides a mechanism for multicast forwarding based on IGMP membership information without the need for more complicated multicast routing protocols

Head-of-Line (HOL) blocking

HOL blocking prevention

Loopback detection

Loopback detection provides protection against loops by transmitting loop protocol packets out of ports on which loop protection has been enabled. It operates independently of STP

Layer 3

IPv4 routing

Wire-speed routing of IPv4 packets

Up to 990 static routes and up to 128 IP interfaces

IPv6 routing

Wire-speed routing of IPv6 packets

Layer 3 interface

Configuration of a Layer 3 interface on a physical port, LAG, VLAN interface, or loopback interface

Classless Interdomain Routing (CIDR)

Support for CIDR

Routing Information Protocol (RIP) v2

Support for RIP v2 for dynamic routing

Policy-Based Routing (PBR)

Flexible routing control to direct packets to a different next hop based on an IPv4 or IPv6 Access Control List (ACL)

DHCP server

Switch functions as an IPv4 DHCP server, serving IP addresses for multiple DHCP pools or scopes

Support for DHCP options

DHCP relay at Layer 3

Relay of DHCP traffic across IP domains

User Datagram Protocol (UDP) relay

Relay of broadcast information across Layer 3 domains for application discovery or relaying of Bootstrap Protocol (BOOTP)/DHCP packets

Stacking

Hardware stacking

Up to 8 switches in a stack. Up to 200 ports managed as a single system with hardware failover

Stacking is supported on the following models:

C1300-16P-4X, C1300-24T-4X, C1300-24P-4X, C1300-24FP-4X, C1300-48T-4X, C1300-48P-4X, C1300-48FP-4X

High availability

Fast stack failover delivers minimal traffic loss. Support for LAG across multiple units in a stack

Plug-and-play stacking configuration/management

Active/standby for resilient stack control

Auto-numbering

Hot swap of units in stack

Ring and chain stacking options, auto stacking port speed, flexible stacking port options

High-speed stack interconnects

Cost-effective high-speed 10 Gigabit Ethernet fiber interfaces

Security

Secure Shell (SSH) Protocol

SSH is a secure replacement for Telnet traffic. Secure Copy Protocol (SCP) also uses SSH. SSH v1 and v2 are supported

Secure Sockets Layer (SSL)

SSL support: Encrypts all HTTPS traffic, allowing highly secure access to the browser-based management GUI in the switch

IEEE 802.1X (authenticator role)

802.1X: RADIUS authentication and accounting, MD5 hash, guest VLAN, unauthenticated VLAN, single/multiple host mode, and single/multiple sessions

Supports time-based 802.1X, dynamic VLAN assignment, and MAC authentication

IEEE 802.1X supplicant

A switch can be configured to act as a supplicant to another switch. This enables extended secure access in areas outside the wiring closet (such as conference rooms)

Web-based authentication

Web-based authentication provides network admission control through a web browser to any host devices and operating systems

STP Bridge Protocol Data Unit (BPDU) Guard

A security mechanism to protect the network from invalid configurations. A port enabled for BPDU Guard is shut down if a BPDU message is received on that port. This avoids accidental topology loops

STP Root Guard

Prevents edge devices not in the network administrator’s control from becoming STP root nodes

STP loopback guard

Provides additional protection against Layer 2 forwarding loops (STP loops)

DHCP snooping

Filters out DHCP messages with unregistered IP addresses and/or from unexpected or untrusted interfaces. This prevents rogue devices from behaving as DHCP servers

IP Source Guard (IPSG)

When IPSG is enabled at a port, the switch filters out IP packets received from the port if the source IP addresses of the packets have not been statically configured or dynamically learned from DHCP snooping. This prevents IP address spoofing

Dynamic ARP Inspection (DAI)

The switch discards ARP packets from a port if there are no static or dynamic IP/MAC bindings or if there is a discrepancy between the source or destination addresses in the ARP packet. This prevents man-in-the-middle attacks

IP/MAC/port binding (IPMB)

The preceding features (DHCP snooping, IPSG, and DAI) work together to prevent Denial-of-Service (DoS) attacks in the network, thereby increasing network availability

Secure Core Technology (SCT)

Makes sure that the switch will receive and process management and protocol traffic no matter how much traffic is received

Secure Sensitive Data (SSD)

A mechanism to manage sensitive data (such as passwords, keys, and so on) securely on the switch, populating this data to other devices and a secure auto-configuration. Access to view the sensitive data as plain text or encrypted is provided according to the user-configured access level and the access method of the user

Trustworthy systems

Trustworthy systems provide a highly secure foundation for Cisco products

Run-time defenses (Executable Space Protection [X-Space], Address Space Layout Randomization [ASLR], Built-In Object Size Checking [BOSC])

Private VLAN

Provides security and isolation between switch ports, which helps ensure that users cannot snoop on other users’ traffic; supports multiple uplinks.

Layer 2 isolation Private VLAN Edge (PVE)

PVE (also known as protected ports) provides Layer 2 isolation between devices in the same VLAN; supports multiple uplinks

Port security

Ability to lock source MAC addresses to ports and limit the number of learned MAC addresses

RADIUS/TACACS+

Supports RADIUS and TACACS authentication. Switch functions as a client

RADIUS accounting

The RADIUS accounting functions allow data to be sent at the start and end of services indicating the number of resources (such as time, packets, bytes, and so on) used during the session

Storm control

Broadcast, multicast, and unknown unicast

DoS prevention

DoS attack prevention

Multiple user privilege levels in CLI

Level 1, 7, and 15 privilege levels

ACLs

Support for up to 1024 rules

Drop or rate limit based on source and destination MAC, VLAN ID, IPv4 or IPv6 address, IPv6 flow label, protocol, port, Differentiated Services Code Point (DSCP)/IP precedence, TCP/UDP source and destination ports, 802.1p priority, Ethernet type, Internet Control Message Protocol (ICMP) packets, IGMP packets, TCP flag; ACL can be applied on both ingress and egress sides

Time-based ACLs supported

Quality of service

Priority levels

8 hardware queues

Scheduling

Strict priority and Weighted Round-Robin (WRR)

Class of service

Port-based, 802.1p VLAN priority-based, IPv4/v6 IP precedence/Type of Service (ToS)/DSCP-based, Differentiated Services (DiffServ), classification and remarking ACLs, trusted QoS

Queue assignment based on DSCP and Class of Service (802.1p/CoS)

Rate limiting

Ingress policer; egress shaping and rate control per VLAN, per port, and flow based; dual-rate 3-color (2R3C) policing

Congestion avoidance

A TCP congestion avoidance algorithm is required to minimize and prevent global TCP loss synchronization

iSCSI traffic optimization

A mechanism for giving priority to iSCSI traffic over other types of traffic

Standards

Standards

IEEE 802.3 10BASE-T Ethernet, IEEE 802.3u 100BASE-TX Fast Ethernet, IEEE 802.3ab 1000BASE-T Gigabit Ethernet, IEEE 802.3ad Link Aggregation Control Protocol, IEEE 802.3z Gigabit Ethernet, IEEE 802.3ae 10 Gbps Ethernet over fiber for LAN, IEEE 802.3an 10GBASE-T 10 Gbps Ethernet over copper twisted pair cable, IEEE 802.3x Flow Control, IEEE 802.1D (STP, GARP, and GVRP), IEEE 802.1Q/p VLAN, IEEE 802.1w Rapid STP, IEEE 802.1s Multiple STP, IEEE 802.1X Port Access Authentication, IEEE 802.3af, IEEE 802.3at, IEEE 802.1AB Link Layer Discovery Protocol, IEEE 802.3az Energy Efficient Ethernet, RFC 768, RFC 783, RFC 791, RFC 792, RFC 793, RFC 813, RFC 826, RFC 879, RFC 896, RFC 854, RFC 855, RFC 856, RFC 858, RFC 894, RFC 919, RFC 920, RFC 922, RFC 950, RFC 951, RFC 1042, RFC 1071, RFC 1123, RFC 1141, RFC 1155, RFC 1157, RFC 1213, RFC 1215, RFC 1286, RFC 1350, RFC 1442, RFC 1451, RFC 1493, RFC 1533, RFC 1541, RFC 1542, RFC 1573, RFC 1624, RFC 1643, RFC 1700, RFC 1757, RFC 1867, RFC 1907, RFC 2011, RFC 2012, RFC 2013, RFC 2030, RFC 2131, RFC 2132, RFC 2233, RFC 2576, RFC 2616, RFC 2618, RFC 2665, RFC 2666, RFC 2674, RFC 2737, RFC 2819, RFC 2863, RFC 3164, RFC 3176, RFC 3411, RFC 3412, RFC 3413, RFC 3414, RFC 3415, RFC 3416, RFC 4330

IPv6

IPv6

IPv6 host mode, IPv6 over Ethernet, dual IPv6/IPv4 stack

IPv6 neighbor and router discovery (ND), IPv6 stateless address auto-configuration, path Maximum Transmission Unit (MTU) discovery

Duplicate Address Detection (DAD), ICMP version 6

DHCPv6 stateful client

IPv6 over IPv4 network with Intrasite Automatic Tunnel Addressing Protocol (ISATAP) tunnel support

IPv6 QoS

Prioritize IPv6 packets in hardware

IPv6 ACL

Drop or rate-limit IPv6 packets in hardware

IPv6 First Hop Security

RA guard

ND inspection

DHCPv6 guard

Neighbor binding table (snooping and static entries)

Neighbor binding integrity check

Multicast Listener Discovery (MLD v1/2) snooping

Deliver IPv6 multicast packets only to the required receivers

MLD proxy

The MLD proxy provides a mechanism for multicast forwarding based on MLD membership information without the need for more complicated multicast routing protocols

IPv6 applications

Web/SSL, Telnet server/SSH, ping, traceroute, Simple Network Time Protocol (SNTP), Trivial File Transfer Protocol (TFTP), SNMP, RADIUS, syslog, DNS client, Telnet client, DHCP client, DHCP auto-config, IPv6 DHCP relay, TACACS+

IPv6 RFCs supported

RFC 4443 (which obsoletes RFC 2463): ICMP version 6

RFC 4291 (which obsoletes RFC 3513): IPv6 address architecture

RFC 4291: IPv6 addressing architecture

RFC 2460: IPv6 specification

RFC 4861 (which obsoletes RFC 2461): neighbor discovery for IPv6

RFC 4862 (which obsoletes RFC 2462): IPv6 stateless address auto-configuration

RFC 1981: path MTU discovery

RFC 4007: IPv6 scoped address architecture

RFC 3484: default address selection mechanism

RFC 5214 (which obsoletes RFC 4214): ISATAP tunneling

RFC 4293: MIB IPv6: textual conventions and general group

RFC 3595: textual conventions for IPv6 flow label

Management

Cisco Business Dashboard

Support for embedded probe for Cisco Business Dashboard running on the switch. Eliminates the need to set up a separate hardware or virtual machine for the Cisco Business Dashboard Probe onsite

Cisco Business mobile app

Mobile app for Cisco Business switch and wireless products. Helps to set up a local network in minutes and provide easy management at your fingertips

Cisco Network Plug and Play (PnP) agent

The Cisco Network PnP solution provides a simple, secure, unified, and integrated offering to ease new branch or campus device rollouts or for provisioning updates to an existing network. The solution provides a unified approach to provision Cisco routers, switches, and wireless devices with a near-zero-touch deployment experience

Supports Cisco PnP Connect

Web user interface

Built-in switch configuration utility for easy browser-based device configuration (HTTP/HTTPS)

Supports simple and advanced mode, configuration, wizards, customizable dashboard, system maintenance, monitoring, online help, and universal search

SNMP

SNMP versions 1, 2c, and 3 with support for traps, and SNMP version 3 User-Based Security Model (USM)

Standard MIBs

lldp-MIB

lldpextdot1-MIB

lldpextdot3-MIB

lldpextmed-MIB

rfc2674-MIB

rfc2575-MIB

rfc2573-MIB

rfc2233-MIB

rfc2013-MIB

rfc2012-MIB

rfc2011-MIB

RFC-1212

RFC-1215

SNMPv2-CONF

SNMPv2-TC

p-bridge-MIB

q-bridge-MIB

rfc1389-MIB

rfc1493-MIB

rfc1611-MIB

rfc1612-MIB

rfc1850-MIB

rfc1907-MIB

rfc2571-MIB

rfc2572-MIB

rfc2574-MIB

rfc2576-MIB

rfc2613-MIB

rfc2665-MIB

rfc2668-MIB

rfc2737-MIB

rfc2925-MIB

rfc3621-MIB

rfc4668-MIB

rfc4670-MIB

trunk-MIB

tunnel-MIB

udp-MIB

draft-ietf-bridge-8021x-MIB

draft-ietf-bridge-rstpmib-04-MIB

draft-ietf-hubmib-etherif-mib-v3-00-MIB

draft-ietf-syslog-device-MIB

ianaaddrfamnumbers-MIB

ianaifty-MIB

ianaprot-MIB

inet-address-MIB

ip-forward-MIB

ip-MIB

RFC1155-SMI

RFC1213-MIB

SNMPv2-MIB

SNMPv2-SMI

SNMPv2-TM

RMON-MIB

rfc1724-MIB

dcb-raj-DCBX-MIB-1108-MIB

rfc1213-MIB

rfc1757-MIB

Private MIBs

CISCOSB-lldp-MIB

CISCOSB-brgmulticast-MIB

CISCOSB-bridgemibobjects-MIB

CISCOSB-bonjour-MIB

CISCOSB-dhcpcl-MIB

CISCOSB-MIB

CISCOSB-wrandomtaildrop-MIB

CISCOSB-traceroute-MIB

CISCOSB-telnet-MIB

CISCOSB-stormctrl-MIB

CISCOSB-ssh-MIB

CISCOSB-socket-MIB

CISCOSB-sntp-MIB

CISCOSB-smon-MIB

CISCOSB-phy-MIB

CISCOSB-multisessionterminal-MIB

CISCOSB-mri-MIB

CISCOSB-jumboframes-MIB

CISCOSB-gvrp-MIB

CISCOSB-endofmib-MIB

CISCOSB-dot1x-MIB

CISCOSB-deviceparams-MIB

CISCOSB-cli-MIB

CISCOSB-cdb-MIB

CISCOSB-brgmacswitch-MIB

CISCOSB-3sw2swtables-MIB

CISCOSB-smartPorts-MIB

CISCOSB-tbi-MIB

CISCOSB-macbaseprio-MIB

CISCOSB-policy-MIB

CISCOSB-env_mib

CISCOSB-sensor-MIB

CISCOSB-aaa-MIB

CISCOSB-application-MIB

CISCOSB-bridgesecurity-MIB

CISCOSB-copy-MIB

CISCOSB-CpuCounters-MIB

CISCOSB-Custom1BonjourService-MIB

CISCOSB‑dhcp-MIB

CISCOSB-dlf-MIB

CISCOSB-dnscl-MIB

CISCOSB-embweb-MIB

CISCOSB-fft-MIB

CISCOSB-file-MIB

CISCOSB-greeneth-MIB

CISCOSB-interfaces-MIB

CISCOSB-interfaces_recovery-MIB

CISCOSB-ip-MIB

CISCOSB-iprouter-MIB

CISCOSB-ipv6-MIB

CISCOSB-mnginf-MIB

CISCOSB-lcli-MIB

CISCOSB-localization-MIB

CISCOSB-mcmngr-MIB

CISCOSB-mng-MIB

CISCOSB-physdescription-MIB

CISCOSB-PoE-MIB

CISCOSB-protectedport-MIB

CISCOSB-rmon-MIB

CISCOSB-rs232-MIB

CISCOSB-SecuritySuite-MIB

CISCOSB-snmp-MIB

CISCOSB-specialbpdu-MIB

CISCOSB-banner-MIB

CISCOSB-syslog-MIB

CISCOSB-TcpSession-MIB

CISCOSB-traps-MIB

CISCOSB-trunk-MIB

CISCOSB-tuning-MIB

CISCOSB-tunnel-MIB

CISCOSB-udp-MIB

CISCOSB-vlan-MIB

CISCOSB-ipstdacl-MIB

CISCOSB-eee-MIB

CISCOSB-ssl-MIB

CISCOSB-qosclimib-MIB

CISCOSB-digitalkeymanage-MIB

CISCOSB-tbp-MIB

CISCOSMB-MIB

CISCOSB-secsd-MIB

CISCOSB-draft-ietf-entmib-sensor-MIB

CISCOSB-draft-ietf-syslog-device-MIB

CISCOSB-rfc2925-MIB

CISCO-SMI-MIB

CISCOSB-DebugCapabilities-MIB

CISCOSB-CDP-MIB

CISCOSB-vlanVoice-MIB

CISCOSB-EVENTS-MIB

CISCOSB-sysmng-MIB

CISCOSB-sct-MIB

CISCO-TC-MIB

CISCO-VTP-MIB

CISCO-CDP-MIB

Remote Monitoring (RMON)

Embedded RMON software agent supports 4 RMON groups (history, statistics, alarms, and events) for enhanced traffic management, monitoring, and analysis

IPv4 and IPv6 dual stack

Coexistence of both protocol stacks to ease migration

Firmware upgrade

Web browser upgrade (HTTP/HTTPS) and TFTP and upgrade over SCP running over SSH

Dual images for resilient firmware upgrades

Port mirroring

Traffic on a port can be mirrored to another port for analysis with a network analyzer or RMON probe. Up to 8 source ports can be mirrored to one destination port

VLAN mirroring

Traffic from a VLAN can be mirrored to a port for analysis with a network analyzer or RMON probe. Up to 8 source VLANs can be mirrored to one destination port

Flow-based redirection and mirroring

Redirect or mirror traffic to a destination port or mirroring session based on flow

Remote Switch Port Analyzer (RSPAN)

Traffic can be mirrored across a Layer 2 domain to a remote port on a different switch for easier troubleshooting

sFlow agent

Switch can export sFlow sample to external collectors. sFlow provides visibility into network traffic down to the flow level

DHCP (options 12, 59, 60, 66, 67, 82, 125, 129, and 150)

DHCP options facilitate tighter control from a central point (DHCP server) to obtain IP address, auto-configuration (with configuration and image file download), DHCP relay, and hostname

Secure Copy (SCP)

Securely transfer files to and from the switch

Auto-configuration with SCP file download

Enables secure mass deployment with protection of sensitive data

Text-editable configuration files

Configuration files can be edited with a text editor and downloaded to another switch, facilitating easier mass deployment

Smartports

Simplified configuration of QoS and security capabilities

Auto Smartports

Applies the intelligence delivered through the Smartport roles and applies it automatically to the port based on the devices discovered over Cisco Discovery Protocol or LLDP-MED. This facilitates zero-touch deployments

Text view CLI

Scriptable CLI. A full CLI as well as a menu-based CLI is supported. User privilege levels 1, 7, and 15 are supported for the CLI

Localization

Localization of GUI and documentation into multiple languages

Login banner

Configurable multiple banners for web as well as CLI

Other management

Traceroute, single IP management, HTTP/HTTPS, SSH, RADIUS, port mirroring, TFTP upgrade, DHCP client, BOOTP, SNTP, Xmodem upgrade, cable diagnostics, ping, syslog, Telnet client (SSH secure support), automatic time settings from management station

Green (power efficiency)

Energy detect

Automatically turns power off on an RJ-45 port when the detecting link down. Active mode is resumed without loss of any packets when the switch detects the link is up

Cable length detection

Adjusts the signal strength based on the cable length. Reduces the power consumption for shorter cables

EEE compliant (802.3az)

Supports IEEE 802.3az on all copper Gigabit Ethernet ports

Disable port LEDs

LEDs can be manually turned off to save energy

Time-based port operation

Link up or down based on user-defined schedule (when the port is administratively up)

Time-based PoE

PoE power can be on or off based on a user-defined schedule to save energy

Persistent PoE

Provides PoE power while the device is rebooting

General

Jumbo frames

Frame sizes up to 9000 bytes. The default MTU is 2000 bytes

MAC table

16,000 addresses

Chip guard

Detects tampering attempts and responds during bootup

Boot integrity

Boot integrity visibility allows Cisco’s platform identity and software integrity information to be visible and actionable

Discovery

Bonjour

The switch advertises itself using the Bonjour protocol

Link Layer Discovery Protocol (LLDP) (802.1ab) with LLDP‑Media Endpoint Discovery (MED) extensions

LLDP allows the switch to advertise its identification, configuration, and capabilities to neighboring devices that store the data in a MIB. LLDP-MED is an enhancement to LLDP that adds the extensions needed for IP phones.

Cisco Discovery Protocol

The switch advertises itself using the Cisco Discovery Protocol. It also learns the connected device and its characteristics via Cisco Discovery Protocol

Power over Ethernet (PoE)

802.3af PoE, 802.3at PoE+

The following switches support 802.3at PoE+, 802.3af, and Cisco pre-standard (legacy) PoE. The total power available for PoE per switch is as follows:

Model

Power dedicated to PoE

Number of ports that support PoE

C1300-8P-E-2G

67W

8

C1300-8FP-2G

120W

8

C1300-16P-2G

120W

16

C1300-16FP-2G

240W

16

C1300-24P-4G

195W

24

C1300-24FP-4G

375W

24

C1300-48P-4G

375W

48

C1300-48FP-4G

740W

48

C1300-16P-4X

120W

16

C1300-24P-4X

195W

24

C1300-24FP-4X

375W

24

C1300-48P-4X

375W

48

C1300-48FP-4X

740W

48

Hardware

Power consumption
(worst case)

Model

System power consumption

Power consumption (with PoE)

Heat dissipation (BTU/hr)

C1300-8T-E-2G

110V=12.55W

220V=12.56W

42.86

C1300-8P-E-2G

110V=13.84W

220V=14.31W

110V=80.79W

220V=80.86W

275.91

C1300-8FP-2G

110V=17.29W

220V=17.88W

110V=148.12W

220V=146.36W

505.41

C1300-16T-2G

110V=18.63W

220V=18.37W

64.46

C1300-16P-2G

110V=24.51W

220V=25.01W

110V=156.4W

220V=154.5W

536.39

C1300-16FP-2G

110V=27.53W

220V=26.68W

110V=284W

220V=279.8W

971.78

C1300-24T-4G

110V=25.91W

220V=25.63W

89.13

C1300-24P-4G

110V=34.42W

220V=33.09W

110V=239.7W

220V=236.4W

820.62

C1300-24FP-4G

110V=46.60W

220V=46.35W

110V=449.7W

220V=438.3W

1537.17

C1300-48T-4G

110V=48.27W

220V=48.64W

165.96

C1300-48P-4G

110V=60.77W

220V=59.73W

110V=451.95W

220V=445.85W

1542.12

C1300-48FP-4G

110V=73.79W

220V=74.03W

110V=886.42W

220V=859.50W

3024.59

C1300-16P-4X

110V=27.53W

220V=26.68W

110V=284W

220V=279.8W

971.78

C1300-24T-4X

110V=27.54W

220V=27.25W

93.32

C1300-24P-4X

110V=35.72W

220V=34.53W

110V=240.4W

220V=236.9W

823.01

C1300-24FP-4X

110V=47.14W

220V=47.01W

110V=451.8W

220V=437.4W

1544.34

C1300-48T-4X

110V=51.01W

220V=50.58W

174.06

C1300-48P-4X

110V=61.53W

220V=60.73W

110V=471.90W

220V=463.32W

1610.19

C1300-48FP-4X

110V=76.18W

220V=76.22W

110V=889.35W

220V=865.02W

3034.59

Ports

Model

Total system ports

RJ-45 ports

Combo ports (RJ-45 + Small Form-Factor Pluggable [SFP])

C1300-8T-E-2G

10x Gigabit Ethernet

8x Gigabit Ethernet

2x Gigabit Ethernet combo

C1300-8P-E-2G

10x Gigabit Ethernet

8x Gigabit Ethernet

2x Gigabit Ethernet combo

C1300-8FP-2G

10x Gigabit Ethernet

8x Gigabit Ethernet

2x Gigabit Ethernet combo

C1300-16T-2G

18x Gigabit Ethernet

16x Gigabit Ethernet

2x SFP

C1300-16P-2G

18x Gigabit Ethernet

16x Gigabit Ethernet

2x SFP

C1300-16FP-2G

18x Gigabit Ethernet

16x Gigabit Ethernet

2x SFP

C1300-24T-4G

28x Gigabit Ethernet

24x Gigabit Ethernet

4x SFP

C1300-24P-4G

28x Gigabit Ethernet

24x Gigabit Ethernet

4x SFP

C1300-24FP-4G

28x Gigabit Ethernet

24x Gigabit Ethernet

4x SFP

C1300-48T-4G

52x Gigabit Ethernet

48x Gigabit Ethernet

4x SFP

C1300-48P-4G

52x Gigabit Ethernet

48x Gigabit Ethernet

4x SFP

C1300-48FP-4G

52x Gigabit Ethernet

48 x Gigabit Ethernet

4x SFP

C1300-16P-4X

16x Gigabit Ethernet +
4x 10 Gigabit Ethernet

16x Gigabit Ethernet

4x SFP+

C1300-24T-4X

24x Gigabit Ethernet +
4x 10 Gigabit Ethernet

24x Gigabit Ethernet

4x SFP+

C1300-24P-4X

24x Gigabit Ethernet +
4x 10 Gigabit Ethernet

24x Gigabit Ethernet

4x SFP+

C1300-24FP-4X

24x Gigabit Ethernet +
4x 10 Gigabit Ethernet

24x Gigabit Ethernet

4x SFP+

C1300-48T-4X

48x Gigabit Ethernet +
4x 10 Gigabit Ethernet

48x Gigabit Ethernet

4x SFP+

C1300-48P-4X

48x Gigabit Ethernet +
4x 10 Gigabit Ethernet

48x Gigabit Ethernet

4x SFP+

C1300-48FP-4X

48 Gigabit Ethernet +
4x 10 Gigabit Ethernet

48x Gigabit Ethernet

4x SFP+

Console port

Cisco standard RJ-45 console port and USB Type C port

USB port

USB Type C port on the front panel of the switch for easy file and image management as well as console port

Buttons

Reset button

Cabling type

Unshielded Twisted Pair (UTP) Category 5e or better for 1000BASE-T

LEDs

System, Link/Act, PoE, Speed

Flash

512 MB

CPU

ARM dual-core at 1.4 GHz

DRAM

1 GB DDR4

Packet buffer

All numbers are aggregate across all ports, as the buffers are dynamically shared:

Model

Packet buffer

C1300-8T-E-2G

1.5 MB

C1300-8P-E-2G

1.5 MB

C1300-8FP-2G

1.5 MB

C1300-16T-2G

1.5 MB

C1300-16P-2G

1.5 MB

C1300-16FP-2G

1.5 MB

C1300-24T-4G

1.5 MB

C1300-24P-4G

1.5 MB

C1300-24FP-4G

1.5 MB

C1300-48T-4G

3 MB

C1300-48P-4G

3 MB

C1300-48FP-4G

3 MB

C1300-16P-4X

1.5 MB

C1300-24T-4X

1.5 MB

C1300-24P-4X

1.5 MB

C1300-24FP-4X

1.5 MB

C1300-48T-4X

3 MB

C1300-48P-4X

3 MB

Supported SFP modules

SKU

Media

Speed

Maximum distance

MGBSX1

Multimode fiber

1000 Mbps

500 m

MGBLX1

Single-mode fiber

1000 Mbps

10 km

MGBLH1

Single-mode fiber

1000 Mbps

40 km

MGBT1

UTP Cat 5e

1000 Mbps

100 m

GLC-SX-MMD

Multimode fiber

1000 Mbps

550 m

GLC-LH-SMD

Single-mode fiber

1000 Mbps

10 km

GLC-BX-U

Single-mode fiber

1000 Mbps

10 km

GLC-BX-D

Single-mode fiber

1000 Mbps

10 km

GLC-TE

UTP Cat 5e

1000 Mbps

100 m

SFP-H10GB-CU1M

Copper coax

10 Gigabit Ethernet

1 m

SFP-H10GB-CU3M

Copper coax

10 Gigabit Ethernet

3 m

SFP-H10GB-CU5M

Copper coax

10 Gigabit Ethernet

5 m

SFP-10G-SR

Multimode fiber

10 Gigabit Ethernet

26 m to 400 m

SFP-10G-LR

Single-mode fiber

10 Gigabit Ethernet

10 km

SFP-10G-SR-S

Multimode fiber

10 Gigabit Ethernet

26 m to 400 m

SFP-10G-LR-S

Single-mode fiber

10 Gigabit Ethernet

10 km

Environmental

Unit dimensions
(W x D x H)

Model

Unit dimensions

C1300-8T-E-2G

268 x 185 x 44 mm (10.56 x 7.28 x 1.73 in)

C1300-8P-E-2G

268 x 185 x 44 mm (10.56 x 7.28 x 1.73 in)

C1300-8FP-2G

268 x 272 x 44 mm (10.56 x 10.71 x 1.73 in)

C1300-16T-2G

268 x 272 x 44 mm (10.56 x 10.69 x 1.73 in)

C1300-16P-2G

268 x 297 x 44 mm (10.56 x 11.69 x 1.73 in)

C1300-16FP-2G

268 x 308 x 44 mm (10.56 x 12.14 x 1.73 in)

C1300-24T-4G

445 x 240 x 44 mm (17.5 x 9.45 x 1.73 in)

C1300-24P-4G

445 x 299 x 44 mm (17.5 x 11.77 x 1.73 in)

C1300-24FP-4G

445 x 345 x 44 mm (17.5 x 13.59 x 1.73 in)

C1300-48T-4G

445 x 288 x 44 mm (17.5 x 11.33 x 1.73 in)

C1300-48P-4G

445 x 350 x 44 mm (17.5 x 13.78 x 1.73 in)

C1300-48FP-4G

445 x 350 x 44 mm (17.5 x 13.78 x 1.73 in)

C1300-16P-4X

268 x 297 x 44 mm (10.56 x 11.69 x 1.73 in)

C1300-24T-4X

445 x 240 x 44 mm (17.5 x 9.45 x 1.73 in)

C1300-24P-4X

445 x 299 x 44 mm (17.5 x 11.77 x 1.73 in)

C1300-24FP-4X

445 x 345 x 44 mm (17.5 x 13.59 x 1.73 in)

C1300-48T-4X

445 x 288 x 44 mm (17.5 x 11.33 x 1.73 in)

C1300-48P-4X

445 x 350 x 44 mm (17.5 x 13.78 x 1.73 in)

C1300-48FP-4X

445 x 350 x 44 mm (17.5 x 13.78 x 1.73 in)

Unit weight

Model

Unit weight

C1300-8T-E-2G

1.39 kg (3.06 lb)

C1300-8P-E-2G

1.53 kg (3.37 lb)

C1300-8FP-2G

2.59 kg (5.71 lb)

C1300-16T-2G

1.78 kg (3.92 lb)

C1300-16P-2G

2.38 kg (5.25 lb)

C1300-16FP-2G

2.49 kg (5.49 lb)

C1300-24T-4G

2.63 kg (5.80 lb)

C1300-24P-4G

3.53 kg (7.78 lb)

C1300-24FP-4G

4.6 kg (10.14 lb)

C1300-48T-4G

3.95 kg (8.71 lb)

C1300-48P-4G

5.43 kg (11.97 lb)

C1300-48FP-4G

5.82 kg (12.83 lb)

C1300-16P-4X

2.49 kg (5.49 lb)

C1300-24T-4X

2.78 kg (6.13 lb)

C1300-24P-4X

3.68 kg (8.11 lb)

C1300-24FP-4X

4.6 kg (10.14 lb)

C1300-48T-4X

3.95 kg (8.71 lb)

C1300-48P-4X

5.43 kg (11.97 lb)

Power

100-240V 50-60 Hz, internal, universal: C1300-8FP-2G, C1300-16T-2G, C1300-16P-2G, C1300-16FP-2G, C1300-24T-4G, C1300-24P-4G, C1300-24FP-4G, C1300-48T-4G, C1300-48P-4G, C1300-48FP-4G, C1300-16P-4X, C1300-24T-4X, C1300-24P-4X, C1300-24FP-4X, C1300-48T-4X, C1300-48P-4X.

100-240V 50-60 Hz, external: C1300-8T-E-2G, C1300-8P-E-2G

Certifications

UL (UL 62368), CSA (CSA 22.2), CE mark, FCC Part 15 (CFR 47) Class A

Operating temperature

23° to 122°F (-5° to 50°C)

C1300-8T-E-2G, C1300-8P-E-2G, C1300-8FP-2G, C1300-16T-2G, C1300-16P-2G, C1300-16FP-2G, C1300-24T-4G, C1300-24P-4G, C1300-24FP-4G, C1300-48T-4G, C1300-48P-4G, C1300-48FP-4G, C1300-16P-4X, C1300-24T-4X, C1300-24P-4X, C1300-24FP-4X, C1300-48T-4X, C1300-48P-4X

32° to 122°F (0° to 50°C)

Storage temperature

-13° to 158°F (-25° to 70°C)

Operating humidity

10% to 90%, relative, noncondensing

Storage humidity

10% to 90%, relative, noncondensing

Acoustic noise and mean time between failures (MTBF)

Model

FAN (number)

Acoustic noise

MTBF at 25°C (hours)

C1300-8T-E-2G

Fanless

2,171,669

C1300-8P-E-2G

Fanless

1,706,649

C1300-8FP-2G

Fanless

1,786,412

C1300-16T-2G

Fanless

2,165,105

C1300-16P-2G

Fanless

706,983

C1300-16FP-2G

Fanless

706,983

C1300-24T-4G

Fanless

2,026,793

C1300-24P-4G

Fanless

698,220

C1300-24FP-4G

1

25°C: 34.8 dBA

698,220

C1300-48T-4G

1

25°C: 29.7 dBA

1,452,667

C1300-48P-4G

1

25°C: 37.3 dBA

856,329

C1300-48FP-4G

1

25°C: 48.7 dBA

856,301

C1300-16P-4X

Fanless

2,165,105

C1300-24T-4X

Fanless

2,026,793

C1300-24P-4X

Fanless

698,220

C1300-24FP-4X

1

25°C: 34.8 dBA

698,220

C1300-48T-4X

1

25°C: 29.7 dBA

1,452,667

C1300-48P-4X

1

25°C: 37.3 dBA

856,329

C1300-48FP-4X

1

25°C: 48.7 dBA

856,301

Warranty

Limited lifetime with next-business-day advance replacement (where available)

Package contents

  Cisco Catalyst 1300 Series Switch
  Power cord (power adapter for select 8-port and 16-port SKUs)
  Mounting kit
  Pointer card

Minimum requirements

  Web browser: Chrome, Firefox, Edge, Safari
  Category 5e Ethernet network cable
  TCP/IP, network adapter, and network operating system (such as Microsoft Windows, Linux, or Mac OS X) installed

在售产品

C1300系列交换机

loading…

已经是到最后一篇内容了!

选配信息

Table 2 provides ordering information for the Cisco Catalyst 1300 Series Switches.

Table 2.        Ordering information

Model

Order product ID

Description

Gigabit Ethernet

C1300-8T-E-2G

C1300-8T-E-2G-xx

*  8x 10/100/1000 ports
*  2x Gigabit copper/SFP combo ports
*  Rack-mountable

C1300-8P-E-2G

C1300-8P-E-2G-xx

*  8x 10/100/1000 PoE+ ports with 60W power budget
*  2x Gigabit copper/SFP combo ports
*  Rack-mountable

C1300-8FP-2G

C1300-8FP-2G-xx

*  8x 10/100/1000 PoE+ ports with 120W power budget
*  2x Gigabit copper/SFP combo ports
*  Rack-mountable

C1300-16T-2G

C1300-16T-2G-xx

*  16x 10/100/1000 ports
*  2x Gigabit SFP
*  Rack-mountable

C1300-16P-2G

C1300-16P-2G-xx

*  16x 10/100/1000 PoE+ ports with 120W power budget
*  2x Gigabit SFP
*  Rack-mountable

C1300-16FP-2G

C1300-16FP-2G-xx

*  16x 10/100/1000 PoE+ ports with 240W power budget
*  2x Gigabit SFP
*  Rack-mountable

C1300-24T-4G

C1300-24T-4G-xx

*  24x 10/100/1000 ports
*  4x Gigabit SFP
*  Rack-mountable

C1300-24P-4G

C1300-24P-4G-xx

*  24x 10/100/1000 PoE+ ports with 195W power budget
*  4x Gigabit SFP
*  Rack-mountable

C1300-24FP-4G

C1300-24FP-4G-xx

*  24x 10/100/1000 PoE+ ports with 370W power budget
*  4x Gigabit SFP
*  Rack-mountable

C1300-48T-4G

C1300-48T-4G-xx

*  48x 10/100/1000 ports
*  4x Gigabit SFP
*  Rack-mountable

C1300-48P-4G

C1300-48P-4G-xx

*  48x 10/100/1000 PoE+ ports with 370W power budget
*  4x Gigabit SFP
*  Rack-mountable

Gigabit Ethernet with 10 Gigabit Ethernet uplinks

C1300-16P-4X

C1300-16P-4X-xx

*  16x 10/100/1000 ports PoE+ ports with 120W power budget
*  4x 10 Gigabit SFP+
*  Rack-mountable

C1300-24T-4X

C1300-24T-4X-xx

*  24x 10/100/1000 ports
*  4x 10 Gigabit SFP+
*  Rack-mountable

C1300-24P-4X

C1300-24P-4X-xx

*  24x 10/100/1000 PoE+ ports with 195W power budget
*  4x 10 Gigabit SFP+
*  Rack-mountable

C1300-24FP-4X

C1300-24FP-4X-xx

*  24x 10/100/1000 PoE+ ports with 370W power budget
*  4x 10 Gigabit SFP+
*  Rack-mountable

C1300-48T-4X

C1300-48T-4X-xx

*  48x 10/100/1000 ports
*  4x 10 Gigabit SFP+
*  Rack-mountable

C1300-48P-4X

C1300-48P-4X-xx

*  48x 10/100/1000 PoE+ ports with 370W power budget
*  4x 10 Gigabit SFP+
*  Rack-mountable

Supported SFP/SFP+ modules

SKU

Media

Speed

Maximum distance

MGBSX1

Multimode fiber

1000 Mbps

500 m

MGBLH1

Single-mode fiber

1000 Mbps

40 km

MGBLX1

Single-mode fiber

1000 Mbps

10 km

MGBT1

UTP Cat 5e

1000 Mbps

100 m

GLC-SX-MMD

Multimode fiber

1000 Mbps

550 m

GLC-LH-SMD

Single-mode fiber

1000 Mbps

10 km

GLC-BX-U

Single-mode fiber

1000 Mbps

10 km

GLC-BX-D

Single-mode fiber

1000 Mbps

10 km

GLC-TE

UTP Cat 5e

1000 Mbps

100 m

SFP-H10GB-CU1M

Copper coax

10 Gigabit Ethernet

1 m

SFP-H10GB-CU3M

Copper coax

10 Gigabit Ethernet

3 m

SFP-H10GB-CU5M

Copper coax

10 Gigabit Ethernet

5 m

SFP-10G-SR

Multimode fiber

10 Gigabit Ethernet

26 m – 400 m

SFP-10G-LR

Single-mode fiber

10 Gigabit Ethernet

10 km

SFP-10G-SR-S

Multimode fiber

10 Gigabit Ethernet

26 m to 400 m

SFP-10G-LR-S

Single-mode fiber

10 Gigabit Ethernet

10 km

③采购咨询:186-1111-5727
批量采购咨询
批量采购咨询 提交咨询

Warning: Illegal string offset 'after_widget' in /www/wwwroot/www.szww.cn/webdocs/wp-content/plugins/woocommerce/includes/abstracts/abstract-wc-widget.php on line 178
