思科工业交换机 IE4000

Cisco Industrial Ethernet 4000 Series Switches

— 在您的工业网络中部署安全而灵活的可扩展交换解决方案。 —

① ok采购咨询:186-1111-5727

Cisco Industrial Ethernet 4000 Series Switches

最大限度地延长恶劣工业环境下的正常运行时间
Cisco-Switch-Industrial-IE4000

专为极端环境而设计的工业交换机

思科工业以太网交换机

思科工业以太网 (IE) 4000 系列为恶劣环境提供一流的速度、安全性和可靠性。其行业领先的环协议、边缘计算和先进的工业协议支持弹性和可扩展的网络。IE 4000 系列满足各行业的所有合规性要求。

②采购咨询:186-1111-5727

思科IE4000系列交换机/核心参数对比

Cisco Industrial Ethernet 4000 Series Switches Compare
IE4000 switch with 16 GE Copper and 4 GE combo uplink portsIE-4000-16GT4G-E
  • 型号SKU:IE-4000-16GT4G-E
  • 总端口数: 20
  • 上行端口: 4个千兆复用Combo口
  • 下行端口: 16个千兆电口
  • 交换容量: 20 Gbps
  • POE预算: N/A
  • 默认许可: LAN Base 可升IP Services
  • 设备尺寸: 15.5 x 15.5 x 12.9 cm
  • 设备重量: 2.88 kg
  • 查看详情 >
IE4000 switch with 16 FE Copper and 4 GE combo uplink portsIE-4000-16T4G-E
  • 型号SKU:IE-4000-16T4G-E
  • 总端口数: 20
  • 上行端口: 4个千兆复用Combo口
  • 下行端口: 16个百兆电口
  • 交换容量: 20 Gbps
  • POE预算: N/A
  • 默认许可: LAN Base 可升IP Services
  • 设备尺寸: 15.5 x 15.5 x 12.9 cm
  • 设备重量: 2.88 kg
  • 查看详情 >
IE4000 switch with 4 GE combo, 4 GE PoE+ and 4 GE combo uplink portsIE-4000-4GC4GP4G-E
  • 型号SKU:IE-4000-4GC4GP4G-E
  • 总端口数: 12
  • 上行端口: 4个千兆复用Combo口
  • 下行端口: 4xGE SFP光,4xGE电口PoE+
  • 交换容量: 20 Gbps
  • POE预算: 125 W
  • 默认许可: LAN Base 可升IP Services
  • 设备尺寸: 15.5 x 15.5 x 12.9 cm
  • 设备重量: 2.88 kg
  • 查看详情 >
IE4000 switch with 4 GE SFP, 8 GE PoE+ and 4 GE combo uplink portsIE-4000-4GS8GP4G-E
  • 型号SKU:IE-4000-4GS8GP4G-E
  • 总端口数: 16
  • 上行端口: 4个千兆复用Combo口
  • 下行端口: 4xGE SFP光,8xGE电口PoE+
  • 交换容量: 20 Gbps
  • POE预算: 125 W
  • 默认许可: LAN Base 可升IP Services
  • 设备尺寸: 15.5 x 15.5 x 12.9 cm
  • 设备重量: 2.88 kg
  • 查看详情 >
IE4000 switch with 4 FE SFP, 8 FE PoE+ and 4 GE combo uplink portsE-4000-4S8P4G-E
  • 型号SKU:IE-4000-4S8P4G-E
  • 总端口数: 16
  • 上行端口: 4个千兆复用Combo口
  • 下行端口: 4xFE SFP光,8xFE PoE+口
  • 交换容量: 20 Gbps
  • POE预算: 125 W
  • 默认许可: LAN Base 可升IP Services
  • 设备尺寸: 15.5 x 15.5 x 12.9 cm
  • 设备重量: 2.88 kg
  • 查看详情 >
IE4000 switch with 4 FE Copper, 4 FE PoE+ and 4 GE combo uplink portsIE-4000-4T4P4G-E
  • 型号SKU:IE-4000-4T4P4G-E
  • 总端口数: 12
  • 上行端口: 4个千兆复用Combo口
  • 下行端口: 4xFE 电口,4xFE PoE+口
  • 交换容量: 20 Gbps
  • POE预算: 125 W
  • 默认许可: LAN Base 可升IP Services
  • 设备尺寸: 15.5 x 15.5 x 12.9 cm
  • 设备重量: 2.88 kg
  • 查看详情 >
IE4000 switch with 4 FE Copper combo ports and 4 GE combo uplink portsIE-4000-4TC4G-E
  • 型号SKU:IE-4000-4TC4G-E
  • 总端口数: 8
  • 上行端口: 4个千兆复用Combo口
  • 下行端口: 4个百兆复用Combo口
  • 交换容量: 20 Gbps
  • POE预算: N/A
  • 默认许可: LAN Base 可升IP Services
  • 设备尺寸: 15.5 x 15.5 x 12.9 cm
  • 设备重量: 2.88 kg
  • 查看详情 >
IE4000 switch with 8 GE SFP and 4 GE combo uplink portsIE-4000-8GS4G-E
  • 型号SKU:IE-4000-8GS4G-E
  • 总端口数: 12
  • 上行端口: 4个千兆复用Combo口
  • 下行端口: 8个千兆SFP光口
  • 交换容量: 20 Gbps
  • POE预算: N/A
  • 默认许可: LAN Base 可升IP Services
  • 设备尺寸: 15.5 x 15.5 x 12.9 cm
  • 设备重量: 2.88 kg
  • 查看详情 >
IE4000 switch with 8 GE Copper and 4 GE combo uplink portsIE-4000-8GT4G-E
  • 型号SKU:IE-4000-8GT4G-E
  • 总端口数: 12
  • 上行端口: 4个千兆复用Combo口
  • 下行端口: 8个千兆电
  • 交换容量: 20 Gbps
  • POE预算: N/A
  • 默认许可: LAN Base 可升IP Services
  • 设备尺寸: 15.5 x 15.5 x 12.9 cm
  • 设备重量: 2.88 kg
  • 查看详情 >
IE4000 switch with 8 GE Copper, 8 GE PoE+ and 4 GE combo uplink portsIE-4000-8GT8GP4G-E
  • 型号SKU:IE-4000-8GT8GP4G-E
  • 总端口数: 20
  • 上行端口: 4个千兆复用Combo口
  • 下行端口: 8xGe电口, 8xGE PoE+
  • 交换容量: 20 Gbps
  • POE预算: 240W
  • 默认许可: LAN Base 可升IP Services
  • 设备尺寸: 15.5 x 15.5 x 12.9 cm
  • 设备重量: 2.88 kg
  • 查看详情 >
IE4000 switch with 8 FE SFP and 4 GE combo uplink portsIE-4000-8S4G-E
  • 型号SKU:IE-4000-8S4G-E
  • 总端口数: 12
  • 上行端口: 4个千兆复用Combo口
  • 下行端口: 8xFE SFP光口
  • 交换容量: 20 Gbps
  • POE预算: N/A
  • 默认许可: LAN Base 可升IP Services
  • 设备尺寸: 15.5 x 15.5 x 12.9 cm
  • 设备重量: 2.88 kg
  • 查看详情 >
IE4000 switch with 8 FE copper and 4 GE combo uplink portsIE-4000-8T4G-E
  • 型号SKU:IE-4000-8T4G-E
  • 总端口数: 12
  • 上行端口: 4个千兆复用Combo口
  • 下行端口: 8xFE 电口
  • 交换容量: 20 Gbps
  • POE预算: N/A
  • 默认许可: LAN Base 可升IP Services
  • 设备尺寸: 15.5 x 15.5 x 12.9 cm
  • 设备重量: 2.88 kg
  • 查看详情 >
更多问题,请咨询我们
③ 采购咨询:186-1111-5727
产品介绍
产品参数
在售产品
产品相册

官方描述:Cisco Industrial Ethernet 4000 Series Switches

这些交换机专为承受最恶劣的工业环境而开发,提供最灵活、最具弹性的工业
以太网产品,具有安全连接、简单管理和边缘应用执行功能。

产品概述

Cisco ®工业以太网(IE) 4000 系列为思科加固型交换产品组合提供千兆位连接,具有卓越的高带宽交换能力和经过验证的Cisco IOS ®软件。IE 4000 系列提供高度安全的接入和行业领先的汇聚环协议,以支持弹性和可扩展的网络,同时遵守行业合规性要求。

IE 4000 系列非常适合需要硬化产品的工业以太网应用,包括制造、能源、交通、智能城市。IE4000 内置软件映像验证,以确保思科软件的真实性。凭借改进的整体性能、更大的带宽、先进的安全功能和增强的硬件,Cisco IE 4000 系列补充了相关思科工业交换机(例如 Cisco IE 2000、IE 3200、IE 3300 和 IE 3400)的当前工业以太网产品组合。

IE 4000 系列可用于通过物联网 (IoT) 的软件定义访问扩展轻松、安全地将企业网络扩展到恶劣环境,从而实现室外区域、仓库、配送中心、道路等的连接,使用强大的企业级基于意图的网络管理平台,例如 Cisco DNA Center。

Cisco IE 4000 可以通过基于 GUI 的设备管理器轻松安装,并且还提供开箱即用的工业使用配置和简化的可管理性,以便通过工业网络提供高级安全、数据、视频和语音服务。

特点和优点

表 1 列出了 Cisco IE 4000 系列交换机的功能和优势。

表 1.        Cisco IE 4000 交换机的特性和优势

特征益处
稳健的工业设计●  专为恶劣环境和温度范围(-40 至70 C)而设计。●  经过硬化处理,可抗振动、抗冲击、抗浪涌以及抗噪声。●  通过 4 个千兆位以太网上行链路端口实现弹性双环设计。●  符合自动化、ITS 和变电站环境的多行业规范。●  提高工业系统和设备的正常运行时间、性能和安全性。●  配备紧凑、符合 DIN 导轨标准的外形尺寸,非常适合工业部署。●  涵盖广泛的以太网供电(PoE) 应用要求。
用户友好的 GUI 设备管理器●  允许通过基于Web 的设备管理器轻松配置和监控。●  无需更复杂的终端仿真程序。●  降低部署成本。●  多语言支持 – 英语、中文(繁体)、中文(简体)、法语、德语、日语、西班牙语(拉丁美洲)
SwapDrive:“零配置”替代●  发生故障时可以简单地更换开关。●  无需网络专业知识。●  有助于确保快速恢复。
高密度工业以太网供电 (PoE)●  使用一根电缆即可实现连接和供电,从而降低复杂性。●  通过限制布线、配电板和断路器来控制成本。●  创造空间并减少散热。●  支持即用型PoE 设备,例如IP 电话和无线接入点。●  支持(在部分型号上)最大高清摄像头部署。●  设计支持高达 240W 的 PoE 功率预算(详情请参阅表 2)
全千兆以太网交换机●  连接新的无线接入点(802.11n 和802.11ac)。●  支持新的高清网络摄像机和新的PLC(可编程逻辑控制)。●  允许SCADA(监控和数据采集)连接。●  提供工业领域新的高带宽应用的引入。●  支持对延迟非常敏感的应用和时间敏感的网络。●  为新的网络配置提供多环、冗余环拓扑。●  扩展需要更长距离连接的地理可扩展性。

思科工业以太网 (IE) 4000 系列提供:

●      带宽和容量可根据您的网络需求而增长:20 Gbps 无阻塞交换容量,每个交换机最多 20 个千兆位以太网端口

●      高密度工业 PoE/PoE+ 支持为多达 8 个电源设备提供串联电源,包括 IP 摄像头和电话、徽章阅读器、无线接入点等。

●      Cisco IOS 软件功能可实现平稳的 IT 集成和策略一致性

      双环设计通过 4 个千兆位以太网上行链路端口、弹性以太网协议 (REP)、并行冗余协议 (PRP)、PROFINET – 介质冗余协议 (MRP) 环、高可用性无缝冗余 (HSR) 环、EtherChannel 和 EtherChannel 实现强大的弹性。 Flex Links 支持、冗余电源输入、垂死喘息等。

●      真正的零接触更换,解决半夜或突然发生的故障

●      具有先进硬件辅助功能(如NAT、IEEE1588)的线速、低延迟转发

●      使用通用映像简化软件升级路径

●      支持工业自动化协议 EtherNet/IP (CIP)、PROFINET 和 Modbus TCP

思科 ONE 软件

Cisco ONE 软件提供了一种简化的消费模型,以工业自动化和扩展企业环境中的常见客户场景为中心。Cisco ONE 软件和服务为客户提供四大优势:

●      以极具吸引力的价格满足典型客户使用场景的软件套件

●      通过软件服务支持的许可证可移植性来保护其软件购买的投资

●      通过思科软件支持服务 (SWSS) 获取持续创新和新技术

●      灵活的许可模式,可随着时间的推移平稳分配客户的软件支出

图 1 显示了交换机型号,表 2 列出了所有可用的 Cisco IE 4000 系列型号,表 3 列出了 Cisco IE 4000 系列交换机的电源。

IE 4000 型号

图1。

IE 4000 型号

Ordering information

Product IDDescription
Cisco IE 4000 Hardware PIDs
IE-4000-16GT4G-EIE4000 switch with 16 GE Copper and 4 GE combo uplink ports
IE-4000-16T4G-EIE4000 switch with 16 FE Copper and 4 GE combo uplink ports
IE-4000-4GC4GP4G-EIE4000 switch with 4 GE combo, 4 GE PoE+ and 4 GE combo uplink ports
IE-4000-4GS8GP4G-EIE4000 switch with 4 GE SFP, 8 GE PoE+ and 4 GE combo uplink ports
IE-4000-4S8P4G-EIE4000 switch with 4 FE SFP, 8 FE PoE+ and 4 GE combo uplink ports
IE-4000-4T4P4G-EIE4000 switch with 4 FE Copper, 4 FE PoE+ and 4 GE combo uplink ports
IE-4000-4TC4G-EIE4000 switch with 4 FE Copper combo ports and 4 GE combo uplink ports
IE-4000-8GS4G-EIE4000 switch with 8 GE SFP and 4 GE combo uplink ports
IE-4000-8GT4G-EIE4000 switch with 8 GE Copper and 4 GE combo uplink ports
IE-4000-8GT8GP4G-EIE4000 switch with 8 GE Copper, 8 GE PoE+ and 4 GE combo uplink ports
IE-4000-8S4G-EIE4000 switch with 8 FE SFP and 4 GE combo uplink ports
IE-4000-8T4G-EIE4000 switch with 8 FE copper and 4 GE combo uplink ports
Cisco IE 4000 software licenses and accessories PIDs
IE-LICENSE-SPARESpare license for software upgrade (L2 to L3 features or MRP protocols)
L-IE4000-RTU=IE4000 Electronic software license upgrade from LAN base L2 to IP Services L3 features
LIC-MRP-Manager=MRP ring manager license
LIC-MRP-Client=MRP ring client license
STK-RACK-DINRAIL=19” DIN Rail mount kit
SD-IE-1GB=IE 1GB SD Memory Card – Spare
Cisco ONELicenses
C1F1PIE4K5K1K9Cisco ONE Foundation Lite PerpetualIncludes Prime Infrastructure (LF and AS), Identity Services Engine – Base
C1F1PIE40001K9Cisco ONE Foundation PerpetualIncludes Full flexible Netflow, Stealthwatch, Prime Infrastructure, and Identity Services Engineer – Base
C1A1PIE40001K9Cisco ONE Advanced PerpetualIncludes IP Services
C1-FLOW-IE4KCisco ONE Netflow IE4000
C1A1AIE40001K9Cisco ONE Advanced Perpetual – IE 4000
C1F1AIE40001K9Cisco ONE Foundation Perpetual – IE 4000, BROWNFIELD
C1F1AIE4K5K1K9Cisco ONE Foundation Lite Perpetual – IE 4000/5000
C1F1PIE40001K9Cisco ONE Foundation Perpetual – IE 4000
Cisco IE 4000 DNA licenses
IE4000-DNA-E-LCisco DNA Essentials license (up to 12 ports)
IE4000-DNA-E-L-3YCisco DNA Essentials 3 year term license (up to 12 ports) option
IE4000-DNA-E-L-5YCisco DNA Essentials 5 year term license (up to 12 ports) option
IE4000-DNA-A-LCisco DNA Advantage license (up to 12 ports)
IE4000-DNA-A-L-3YCisco DNA Advantage 3 year term license (up to 12 ports) option
IE4000-DNA-A-L-5YCisco DNA Advantage 5 year term license (up to 12 ports) option
IE4000-DNA-E-MCisco DNA Essentials license (up to 24 ports)
IE4000-DNA-E-M-3YCisco DNA Essentials 3 year term license (up to 24 ports) option
IE4000-DNA-E-M-5YCisco DNA Essentials 5 year term license (up to 24 ports) option
IE4000-DNA-A-MCisco DNA Advantage license (up to 24 ports)
IE4000-DNA-A-M-3YCisco DNA Advantage 3 year term license (up to 24 ports) option
IE4000-DNA-A-M-5YCisco DNA Advantage 5 year term license (up to 24 ports) option
IE4000-DNA-E-L-7YCisco DNA Essentials 7 year term license (up to 12 ports) option
IE4000-DNA-E-M-7YCisco DNA Essentials 7 year term license (up to 24 ports) option
IE4000-DNA-A-L-7YCisco DNA Advantage 7 year term license (up to 12 ports) option
IE4000-DNA-A-M-7YCisco DNA Advantage 7 year term license (up to 24 ports) option

Note:      Cisco DNA Advantage license does not require IP Services license.
