官方描述:MA-PWR-350WAC= Meraki MS390 350W AC Power Supply.

SWITCHING

MA-PWR-350WAC
350W AC power supply
Field-replaceable and hot-swappable for power where and when you need it.

Details that matter
Redundant power supply
Supplies up to 350W of power
For MS390-24, MS390-48

Overview

The Meraki MS390 addresses the most demanding enterprise applications by combining the simplicity of the Meraki dashboard with powerful switching hardware. To satisfy high-bandwidth applications and the deployment of high-speed 802.11ax/wifi-6 access points, the MS390 provides multigigabit ports, 480G stacking, and modular 10/40G uplinks. The MS390 delivers resiliency with fast stack convergence and StackPower. The MS390 provides Adaptive Policy using an over-the-wire tag which segments traffic into security groups to deliver scalable security. The MS390 is integrated under the Meraki dashboard to provide a simply powerful solution to the most demanding wired access applications.

Adaptive Policy provides simple & scalable security policies to segment traffic using Security Groups. Security Groups are created in the dashboard using natural language such as “IOT device” & “Guest.” The security policy intent (e.g., Permit or Deny) is then simply provisioned between Security Groups which results in the segmentation of each group’s traffic. By making security policy management intuitive and scalable relative to legacy IP-address based Access Control Lists, Adaptive Policy empowers operators to confidently secure their network traffic independent of future network changes.

By pooling & distributing power across MS390s using a series of StackPower cables, StackPower provides simple and resilient power distribution across the stack.

Models

Number of PortsModelDescription
 24 Ports MS390-24-HW24-port GbE switch
MS390-24P-HW24-port GbE PoE+ switch
MS390-24U-HW24-port GbE UPoE/802.3bt switch
MS390-24UX-HW24-port mGbE UPoE/802.3bt switch
 48 PortsMS390-48-HW48-port GbE switch
MS390-48P-HW48-port GbE PoE+ switch
MS390-48U-HW48-port GbE UPoE/802.3bt switch
MS390-48UX-HW36-port 2.5GbE + 12-port mGbE UPoE/802.3bt switch
MS390-48UX2-HW48-port 5GbE UPoE/802.3bt switch

交换机商城商务值班经理

微信扫一扫,价格早知道
最新产品
最新商品
促销商品

最新产品

  • SFP-GE-T SFP-GE-(RJ45).

    346
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-GE-T

    SFP-GE-T,华三10G SFP电口光模块,H3C SFP-GE-T,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-GE-PX20-D-SM1490-M SFP 1G Transceiver-(1490nm(Transmit)/1310nm(Recieve),20km,RSSI,SC/PC).

    392
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-GE-PX20-D-SM1490-M

    SFP-GE-PX20-D-SM1490-M,华三1G SFP光模块,H3C SFP-GE-PX20-D-SM1490-M,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-FE-LX-SM1550-BIDI

    329
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-FE-LX-SM1550-BIDI

    SFP-FE-LX-SM1550-BIDI ,华三百兆 SFP光模块,SFP-FE-LX-SM1550-BIDI ,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-FE-LX-SM1310-BIDI

    338
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-FE-LX-SM1310-BIDI

    SFP-FE-LX-SM1310-BIDI,华三百兆 SFP光模块,H3C SFP-FE-LX-SM1310-BIDI,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-GE-LH70-SM1550-BIDI

    320
    • 设备品牌:华三(H3C)
    • 型号SKU: SFP-GE-LH70-SM1550-BIDI

    SFP-GE-LH70-SM1550-BIDI,华三1G SFP光模块,H3C SFP-GE-LH70-SM1550-BIDI,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-GE-LH70-SM1490-BIDI

    325
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-GE-LH70-SM1490-BIDI

    SFP-GE-LX-SM1310-BIDI,华三10G SFP光模块,H3CSFP-GE-LH40-SM1310-BIDI,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

loading…

已经是到最后一篇内容了!

最新商品

  • SFP-GE-T SFP-GE-(RJ45).

    346
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-GE-T

    SFP-GE-T,华三10G SFP电口光模块,H3C SFP-GE-T,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-GE-PX20-D-SM1490-M SFP 1G Transceiver-(1490nm(Transmit)/1310nm(Recieve),20km,RSSI,SC/PC).

    392
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-GE-PX20-D-SM1490-M

    SFP-GE-PX20-D-SM1490-M,华三1G SFP光模块,H3C SFP-GE-PX20-D-SM1490-M,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-FE-LX-SM1550-BIDI

    329
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-FE-LX-SM1550-BIDI

    SFP-FE-LX-SM1550-BIDI ,华三百兆 SFP光模块,SFP-FE-LX-SM1550-BIDI ,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-FE-LX-SM1310-BIDI

    338
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-FE-LX-SM1310-BIDI

    SFP-FE-LX-SM1310-BIDI,华三百兆 SFP光模块,H3C SFP-FE-LX-SM1310-BIDI,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-GE-LH70-SM1550-BIDI

    320
    • 设备品牌:华三(H3C)
    • 型号SKU: SFP-GE-LH70-SM1550-BIDI

    SFP-GE-LH70-SM1550-BIDI,华三1G SFP光模块,H3C SFP-GE-LH70-SM1550-BIDI,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-GE-LH70-SM1490-BIDI

    325
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-GE-LH70-SM1490-BIDI

    SFP-GE-LX-SM1310-BIDI,华三10G SFP光模块,H3CSFP-GE-LH40-SM1310-BIDI,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

loading…

已经是到最后一篇内容了!

促销商品

  • SFP-GE-T SFP-GE-(RJ45).

    346
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-GE-T

    SFP-GE-T,华三10G SFP电口光模块,H3C SFP-GE-T,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-GE-PX20-D-SM1490-M SFP 1G Transceiver-(1490nm(Transmit)/1310nm(Recieve),20km,RSSI,SC/PC).

    392
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-GE-PX20-D-SM1490-M

    SFP-GE-PX20-D-SM1490-M,华三1G SFP光模块,H3C SFP-GE-PX20-D-SM1490-M,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-FE-LX-SM1550-BIDI

    329
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-FE-LX-SM1550-BIDI

    SFP-FE-LX-SM1550-BIDI ,华三百兆 SFP光模块,SFP-FE-LX-SM1550-BIDI ,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-FE-LX-SM1310-BIDI

    338
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-FE-LX-SM1310-BIDI

    SFP-FE-LX-SM1310-BIDI,华三百兆 SFP光模块,H3C SFP-FE-LX-SM1310-BIDI,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-GE-LH70-SM1550-BIDI

    320
    • 设备品牌:华三(H3C)
    • 型号SKU: SFP-GE-LH70-SM1550-BIDI

    SFP-GE-LH70-SM1550-BIDI,华三1G SFP光模块,H3C SFP-GE-LH70-SM1550-BIDI,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-GE-LH70-SM1490-BIDI

    325
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-GE-LH70-SM1490-BIDI

    SFP-GE-LX-SM1310-BIDI,华三10G SFP光模块,H3CSFP-GE-LH40-SM1310-BIDI,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

loading…

已经是到最后一篇内容了!

官方描述:MA-PWR-350WAC= Meraki MS390 350W AC Power Supply.

MA-PWR-350WACMeraki MS390 350W AC Power Supply.$798.30

Features

CategoryFeatures
HighlightsLayer-340G or 10G modular uplink options on all modelsmGig supportDual Dedicated 120G Hardware Stacking PortsPoE+, UPoE Support , 802.3bt (60W)StackPower in a ring topology supporting up to 4 switchesNetflow version 10 (IPFIX) and Encrypted Traffic AnalyticsMicro-Segmentation via Adaptive Policy (Security Group Tags)
ManagementManaged via Cisco Meraki Dashboard Zero-touch remote provisioning (no staging needed)Basic configuration capability via local management pageDetailed historical per-port and per-client usage statisticsOperating System, device, and hostname fingerprintingAutomatic firmware upgrades with scheduling controlSNMP and SYSLOG support for integration with other network management solutions
Remote DiagnosticsEmail, SMS and Mobile push notification alerts1Ping, traceroute, cable testing, and link failure detection with alertingRemote packet captureDynamic and interactive network discovery and topologyCombined event and configuration change logs with instant searchNetflow v10 Exporting
StackingPhysically stack up to 8 switches with 480 Gbps of stacking bandwidth on all modelsVirtual stacking supports thousands of switch ports in a single logical stack for unified management, monitoring, and configurationFaster convergenceStackPower in a ring topology supporting upto 4 switches
Ethernet Switching Capabilities802.1p Quality of Service, 8 queues (w/ 6 configurable for DSCP-to-CoS mapping)802.1Q VLAN and trunking support for up to 4,094 VLANs (1000 active VLANs with STP enabled)Single Instance of 802.1s Multiple Spanning Tree Protocol (interoperable with RSTP, STP, PVST, RPVST)STP Enhancements: BPDU guard, Root guard, Loop guard, UDLDBroadcast storm control802.1ab Link Layer Discovery Protocol (LLDP) and Cisco Discovery Protocol (CDP)802.3ad Link aggregation with up to 8 ports per aggregate, Multichassis aggregates supported on stacked switchesPort mirroringIGMP snooping for multicast filteringMAC Forwarding Entries: 32K
Layer 3Static routing, OSPFv2Multicast routing (PIM-ASM)Warm Spare (VRRP) *DHCP Server, DHCP Relay
SecurityIntegrated multi-factor authentication for Dashboard managementRole-based access control (RBAC) with granular device and configuration controlCorporate wide password policy enforcementIEEE 802.1X RADIUS and MAB, hybrid authentication and RADIUS server testingSingle-Host/Multi-Domain/Multi-Host/Multi AuthenticationPort security: Sticky MAC, MAC whitelisting *DHCP snooping, detection and blocking, Dynamic ARP InspectionIPv4 and IPv6 ACLsAdaptive Policy

* Available in a future software release

MS390 Licensing

MS390 license structure includes two feature tiers:  Enterprise and Advanced. The MS390 also introduces a new and simpler license to hardware mapping, specifically 24-port or 48-port licenses. As with all MS, every MS390 license is available in 1, 3, 5, 7, and 10 year terms.

Meraki Support is unable to upgrade licensing from Enterprise to Advanced for the MS390 model. This upgrade must be purchased as a new license.

MS390 License Structure24-Port Model48-port Model
Advanced FeaturesLIC-MS390-24ALIC-MS390-48A
Enterprise FeaturesLIC-MS390-24ELIC-MS390-48E

Context and Comparisons

 24 Port Models48 Port Models
DescriptionMS350-24XMS355-24X2MS390-24UXMS350-48FPMS355-48X2MS390-48UX2
1GbE RJ45164824
mGbE RJ45824242448
10GbE SFP+44Modular44Modular
40GbE QSFP+n/a2Modular2Modular
Hardware Stack Port2x 40G2x 100G2x 120G2x 40G2x 100G2x 120G
Management Interface111111
Hot Swap PSYes, DualYes, DualYes, DualYes, DualYes, DualYes, Dual
Hot Swap FansYes, 2xYes, 3xYes, 3xYes, 2xYes, 3xYes, 3x
Layer 3 RoutingYesYesYesYesYesYes
UPoE/802.3bt CapableYes, 740WYes, 740WYes, 560WNo, 740W(only PoE/PoE+)Yes, 740WYes, 645W
Max Switching Capacity176 Gbps640 Gbps640 Gbps176 Gbps688 Gbps640 Gbp
Max Stacking Bandwidth160 Gbps400 Gbps480 Gbps160 Gbps400 Gbps480 Gbps

Technical Breakdown

Interfaces Specifications

ModelInterfacesUplink 10/40GbE (SFP+, QSFP+)120G Hardware Stack PortDedicated Management InterfacePoE/ UPoE Capabilities
MS390-24-HW24 x 1GbE RJ45Modular21n/a
MS390-24P-HW24 x 1GbE RJ45Modular21PoE
MS390-24U-HW24 x 1GbE RJ45Modular21UPoE/802.3bt
MS390-24UX-HW24 x 100M/1G/2.5G/5G/10G RJ45Modular21UPoE/802.3bt
MS390-48-HW48 x 1GbE RJ45Modular21n/a
MS390-48P-HW48 x 1GbE RJ45Modular21PoE
MS390-48U-HW48 x 1GbE RJ45Modular21UPoE/802.3bt
MS390-48UX-HW36 x 100M/1G/2.5G +12 x 100M/1G/2.5G/5G/10GModular21UPoE/802.3bt
MS390-48UX2-HW48 x 100M/1G/2.5G/5GModular21UPoE/802.3bt

All models are available with modular uplinks that have been listed under the Accessories list. For supported SFP modules please refer the SFP Datasheet.

Cabling Best Practices for Multi-Gigabit operations: While Category-5e cables can support multigigabit data rates upto 2.5/5 Gbps, external factors such as noise, alien crosstalk coupled with longer cable/cable bundle lengths can impede reliable link operation. Noise can originate from cable bundling, RFI, cable movement, lightning, power surges and other transient event. It is recommended to use Category-6a cabling for reliable multigigabit operations as it mitigates alien crosstalk by design.

Physical Specifications

ModelDimensions (h x w x d)W/ Default Power SupplyWeightMount TypeHot Swap FansOperating Temperature Humidity
MS390-24-HW1.73” x 17.5” x17.7”(4.4 x 44.5 x 44.9cm)16.03 lb (7.27 kg)1U Rack MountYes, 3x-5°C to 45°C5 to 90%
MS390-24P-HW1.73” x 17.5” x17.7”(4.4 x 44.5 x 44.9cm)16.33 lb (7.4 kg)1U Rack MountYes, 3x-5°C to 45°C5 to 90%
MS390-24U-HW1.73” x 17.5” x 19.2”(4.4 x 44.5 x 44.8cm)16.63 lb (7.54 kg)1U Rack MountYes, 3x-5°C to 45°C5 to 90%
MS390-24UX-HW1.73” x 17.5” x 20.2”(4.4 x 44.5 x 51.3cm)18.18 lb (8.25 kg)1U Rack MountYes, 3x-5°C to 45°C5 to 90%
MS390-48-HW1.73” x 17.5” x17.7”(4.4 x 44.5 x 44.9cm)16.43 lb (7.45 kg)1U Rack MountYes, 3x-5°C to 45°C5 to 90%
MS390-48P-HW1.73” x 17.5” x17.7”(4.4 x 44.5 x 44.9cm)16.73 lb (7.59 kg)1U Rack MountYes, 3x-5°C to 45°C5 to 90%
MS390-48U-HW1.73” x 17.5” x 19.2”(4.4 x 44.5 x 48.8cm)17.03 lb (7.72 kg)1U Rack MountYes, 3x-5°C to 45°C5 to 90%
MS390-48UX-HW1.73” x 17.5” x 22.2”(4.4 x 44.5 x 56.4cm)20.50 lb (9.34 kg)1U Rack MountYes, 3x-5°C to 45°C5 to 90%
MS390-48UX2-HW1.73” x 17.5” x 22.2”(4.4 x 44.5 x 56.4cm)20.05 lb (9.09 kg)1U Rack MountYes, 3x-5°C to 45°C5 to 90%

Performance

ModelSwitching CapacityStacking BandwidthForwarding rate
MS390-24-HW208 Gbps480 Gbps154.76 Mpps
MS390-24P-HW208 Gbps480 Gbps154.76 Mpps
MS390-24U-HW208 Gbps480 Gbps154.76 Mpps
MS390-24UX-HW640 Gbps480 Gbps476.19 Mpps
MS390-48-HW256 Gbps480 Gbps190.48 Mpps
MS390-48P-HW256 Gbps480 Gbps190.48 Mpps
MS390-48U-HW256 Gbps480 Gbps190.48 Mpps
MS390-48UX-HW580 Gbps480 Gbps431.54 Mpps
MS390-48UX2-HW640 Gbps480 Gbps476.19 Mpps

Power Options and Specifications

ModelDefault Power SupplyHot Swap Power SupplyAvailable PoE W/ Primary PSAvailable PoE W/ Secondary PS***Power Load(idle/max)
MS390-24-HWMA-PWR-350WAC**Yes, Dualn/an/a79.2 / 99 W
MS390-24P-HWMA-PWR-715WAC**Yes, Dual445W720W84.1 / 554.4 W
MS390-24U-HWMA-PWR-1100WACYes, Dual830W1440W85.4 / 990.3 W
MS390-24UX-HWMA-PWR-1100WACYes, Dual560W1440W162.7 / 809.9 W
MS390-48-HWMA-PWR-350WAC**Yes, Dualn/an/a83.9 / 109.9 W
MS390-48P-HWMA-PWR-715WAC**Yes, Dual437W1152W92.6 / 555 W
MS390-48U-HWMA-PWR-1100WACYes, Dual822W1800W145 / 844.9 W
MS390-48UX-HWMA-PWR-1100WACYes, Dual490W1590W218.5 / 785.5 W
MS390-48UX2-HWMA-PWR-1100WACYes, Dual645W1745W157.9 / 843.8 W

** Upgrade options to 715W and 1100W PSU are available.

*** The PoE values are provided considering the secondary PS to be the default power supply of  the respective model.

What’s included

ModelPackage Contents
MS390-24-HW1 x Power Supply (MA-PWR-350WAC), Rack mount brackets and screw kit, 3 x Pre-Installed Fans, Cable guide
MS390-24P-HW1 x Power Supply (MA-PWR-715WAC), Rack mount brackets and screw kit, 3 x Pre-Installed Fans, Cable guide
MS390-24U-HW1 x Power Supply (MA-PWR-1100WAC), Rack mount brackets and screw kit, 3 x Pre-Installed Fans, Cable guide
MS390-24UX-HW1 x Power Supply (MA-PWR-1100WAC), Rack mount brackets and screw kit, 3 x Pre-Installed Fans, Cable guide
MS390-48-HW1 x Power Supply (MA-PWR-350WAC), Rack mount brackets and screw kit, 3 x Pre-Installed Fans, Cable guide
MS390-48P-HW1 x Power Supply (MA-PWR-715WAC), Rack mount brackets and screw kit, 3 x Pre-Installed Fans, Cable guide
MS390-48U-HW1 x Power Supply (MA-PWR-1100WAC), Rack mount brackets and screw kit, 3 x Pre-Installed Fans, Cable guide
MS390-48UX-HW1 x Power Supply (MA-PWR-1100WAC), Rack mount brackets and screw kit, 3 x Pre-Installed Fans, Cable guide
MS390-48UX2-HW1 x Power Supply (MA-PWR-1100WAC), Rack mount brackets and screw kit, 3 x Pre-Installed Fans, Cable guide

Optional Accessories

AccessoryDescription Supported Models
MA-PWR-350WAC350W AC Power SupplyMS390-24-HW, MS390-48-HW
MA-PWR-715WAC715W AC Power SupplyAll Models
MA-PWR-1100WAC1100W AC Power SupplyAll Models
MA-MOD-2X40G2 x 40G Uplink ModuleAll Models
MA-MOD-4X10G *4 x 10G Uplink ModuleAll Models
MA-MOD-8X10G8 x 10G Uplink ModuleAll Models
MA-CBL-120G-50CMMeraki 120G Stacking Cable, 0.5 MeterAll Models
MA-CBL-120G-1MMeraki 120G Stacking Cable, 1 MeterAll Models
MA-CBL-120G-3MMeraki 120G Stacking Cable, 3 MeterAll Models
MA-CBL-SPWR-30CMMeraki MS390 30CM StackPower CableAll Models
MA-CBL-SPWR-150CMMeraki MS390 150CM StackPower CableAll Models
MA-FAN-16K2System FanAll Models
MA-RCKMNTMeraki MS390 Rack Mount KitAll Models

* MA-MOD-4X10G reached end-of-sale on November 1, 2021. Please refer to its end-of-sale announcement for further details.

Regulations and Compliance

Electromagnetic CompatibilityCertificationsFCC Part 15 (CFR 47) Class A, ICES-003 Class A, CISPR22 Class A, CNS13438, EN 300 386 V1.6.1,  EN 55022 Class A, EN 61000-3-2, EN61000-3-3, KN 32, TCVN 7189 Class A, EN 55032 , CISPR 32 Class A, V-2/2015.04, V-3/2015.04, VCCI-CISPR 32 Class A, CISPR24, EN 300 386 V1.6.1, EN 55024, KN35, TCVN 7317
Safety CAN/CSA-C22.2 No. 60950-1, UL 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
EnvironmentalReduction of Hazardous Substances (RoHS)
WarrantyFull lifetime hardware warranty with next-day advanced replacement included

下载的支持 (软件下载定制,参数文案定制,产品选型培训定制,设备调试培训定制,设备运维服务定制)

IOS软件,3C证书,检测报告,操作手册,安装手册,命令手册,产品教程,配置教程,一对一指导

加入交换机小圈,获得更详细的资料,更专业的支持,更全面的支持教程。(https://q.jhj.cn/thread/3)

如果没有找到满意的资料,可以在交小圈发布请求贴,让更多网友来帮你想办法,或者找找以前有没有类似资源 (https://q.jhj.cn)

交换机商城商务值班经理

微信扫一扫,价格早知道
最新产品
最新商品
促销商品

最新产品

  • SFP-GE-T SFP-GE-(RJ45).

    346
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-GE-T

    SFP-GE-T,华三10G SFP电口光模块,H3C SFP-GE-T,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-GE-PX20-D-SM1490-M SFP 1G Transceiver-(1490nm(Transmit)/1310nm(Recieve),20km,RSSI,SC/PC).

    392
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-GE-PX20-D-SM1490-M

    SFP-GE-PX20-D-SM1490-M,华三1G SFP光模块,H3C SFP-GE-PX20-D-SM1490-M,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-FE-LX-SM1550-BIDI

    329
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-FE-LX-SM1550-BIDI

    SFP-FE-LX-SM1550-BIDI ,华三百兆 SFP光模块,SFP-FE-LX-SM1550-BIDI ,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-FE-LX-SM1310-BIDI

    338
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-FE-LX-SM1310-BIDI

    SFP-FE-LX-SM1310-BIDI,华三百兆 SFP光模块,H3C SFP-FE-LX-SM1310-BIDI,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-GE-LH70-SM1550-BIDI

    320
    • 设备品牌:华三(H3C)
    • 型号SKU: SFP-GE-LH70-SM1550-BIDI

    SFP-GE-LH70-SM1550-BIDI,华三1G SFP光模块,H3C SFP-GE-LH70-SM1550-BIDI,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-GE-LH70-SM1490-BIDI

    325
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-GE-LH70-SM1490-BIDI

    SFP-GE-LX-SM1310-BIDI,华三10G SFP光模块,H3CSFP-GE-LH40-SM1310-BIDI,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

loading…

已经是到最后一篇内容了!

最新商品

  • SFP-GE-T SFP-GE-(RJ45).

    346
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-GE-T

    SFP-GE-T,华三10G SFP电口光模块,H3C SFP-GE-T,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-GE-PX20-D-SM1490-M SFP 1G Transceiver-(1490nm(Transmit)/1310nm(Recieve),20km,RSSI,SC/PC).

    392
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-GE-PX20-D-SM1490-M

    SFP-GE-PX20-D-SM1490-M,华三1G SFP光模块,H3C SFP-GE-PX20-D-SM1490-M,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-FE-LX-SM1550-BIDI

    329
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-FE-LX-SM1550-BIDI

    SFP-FE-LX-SM1550-BIDI ,华三百兆 SFP光模块,SFP-FE-LX-SM1550-BIDI ,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-FE-LX-SM1310-BIDI

    338
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-FE-LX-SM1310-BIDI

    SFP-FE-LX-SM1310-BIDI,华三百兆 SFP光模块,H3C SFP-FE-LX-SM1310-BIDI,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-GE-LH70-SM1550-BIDI

    320
    • 设备品牌:华三(H3C)
    • 型号SKU: SFP-GE-LH70-SM1550-BIDI

    SFP-GE-LH70-SM1550-BIDI,华三1G SFP光模块,H3C SFP-GE-LH70-SM1550-BIDI,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-GE-LH70-SM1490-BIDI

    325
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-GE-LH70-SM1490-BIDI

    SFP-GE-LX-SM1310-BIDI,华三10G SFP光模块,H3CSFP-GE-LH40-SM1310-BIDI,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

loading…

已经是到最后一篇内容了!

促销商品

  • SFP-GE-T SFP-GE-(RJ45).

    346
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-GE-T

    SFP-GE-T,华三10G SFP电口光模块,H3C SFP-GE-T,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-GE-PX20-D-SM1490-M SFP 1G Transceiver-(1490nm(Transmit)/1310nm(Recieve),20km,RSSI,SC/PC).

    392
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-GE-PX20-D-SM1490-M

    SFP-GE-PX20-D-SM1490-M,华三1G SFP光模块,H3C SFP-GE-PX20-D-SM1490-M,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-FE-LX-SM1550-BIDI

    329
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-FE-LX-SM1550-BIDI

    SFP-FE-LX-SM1550-BIDI ,华三百兆 SFP光模块,SFP-FE-LX-SM1550-BIDI ,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-FE-LX-SM1310-BIDI

    338
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-FE-LX-SM1310-BIDI

    SFP-FE-LX-SM1310-BIDI,华三百兆 SFP光模块,H3C SFP-FE-LX-SM1310-BIDI,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-GE-LH70-SM1550-BIDI

    320
    • 设备品牌:华三(H3C)
    • 型号SKU: SFP-GE-LH70-SM1550-BIDI

    SFP-GE-LH70-SM1550-BIDI,华三1G SFP光模块,H3C SFP-GE-LH70-SM1550-BIDI,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-GE-LH70-SM1490-BIDI

    325
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-GE-LH70-SM1490-BIDI

    SFP-GE-LX-SM1310-BIDI,华三10G SFP光模块,H3CSFP-GE-LH40-SM1310-BIDI,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

loading…

已经是到最后一篇内容了!

产品型号图集

如果这想要获得更多高清图册,请加入交小圈获得 https://Q.JHJ.cn 交换机小圈

MA-PWR-350WAC= Meraki MS390 350W AC Power Supply.MA-PWR-350WAC=	Meraki MS390 350W AC Power Supply.

点击放大的图片列表

MA-PWR-350WAC=	Meraki MS390 350W AC Power Supply.
③ 采购咨询:186-1111-5727
批量采购咨询
批量采购咨询 提交咨询
