C9K-CMPCT-DESK-MNT=C9K-CMPCT-DESK-MNT= Under desk mount for compact switches

C9K-CMPCT-DESK-MNT= Under desk mount for compact switches

桌下安装套件用于紧凑型交换机 C9K-CMPCT-DESK-MNT
安装配件 C9200系列交换机
  • 设备品牌:思科(Cisco)
  • 所属系列:思科-配件-安装套件
  • 型号SKU:C9K-CMPCT-DESK-MNT=
  • 匹配产品:C9200系列
  • 采购电话:010-8646 2600
  • 模块选择C9K-CMPCT-DESK-MNT=C9K-CMPCT-DESK-MNT=
加入咨询列表
去旗舰店购买
在线客服

产品资料下载

, , , , , ,
②采购咨询:186-1111-5727
产品介绍
产品参数
资料下载
产品相册

C9K-CMPCT-DESK-MNT= Under desk mount for compact switches

C9K-CMPCT-DESK-MNT=

Table .     Mounting Accessories Ordering information

Product Number

Product Description

ACC-KIT-T1=

Accessory kit with 19 inch Type 1 rack mount

RACK-KIT-T1=

19, 23, 24 inch and ETSI Type 1 rack mount kit

4PT-KIT-T2=

4 Point rack mount kit New

C9K-MGNT-TRAY

Magnet and Mounting Tray for compact switches

C9K-CMPCT-DIN-MNT

DIN Rail Mount for compact switches

RACKMNT-19-CMPACT

19-Inch Rack Mounting Brackets for compact switches

C9K-CMPCT-CBLE-GRD

Cable guard for compact switches (for C9K-WALL-TRAY)

C9K-WALL-TRAY

Wall mount bracket for compact switches

C9K-CMPCT-DESK-MNT

Under desk mount for compact switches
nb-06-cat9200-ser-data-sheet-cte-cn-2019-06-26下载

交换机商城商务值班经理

C9K-CMPCT-DESK-MNT= Under desk mount for compact switches - Cisco C9K-CMPCT-DESK-MNT=（images 3）
微信扫一扫，价格早知道
最新产品
最新商品
促销商品

最新产品

  • SFP-GE-T SFP-GE-(RJ45).

    SFP-GE-T SFP-GE-(RJ45).

    849
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-GE-T

    SFP-GE-T,华三10G SFP电口光模块,H3C SFP-GE-T,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-GE-PX20-D-SM1490-M SFP 1G Transceiver-(1490nm(Transmit)/1310nm(Recieve),20km,RSSI,SC/PC).

    SFP-GE-PX20-D-SM1490-M SFP 1G Transceiver-(1490nm(Transmit)/1310nm(Recieve),20km,RSSI,SC/PC).

    955
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-GE-PX20-D-SM1490-M

    SFP-GE-PX20-D-SM1490-M,华三1G SFP光模块,H3C SFP-GE-PX20-D-SM1490-M,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-FE-LX-SM1550-BIDI

    SFP-FE-LX-SM1550-BIDI

    890
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-FE-LX-SM1550-BIDI

    SFP-FE-LX-SM1550-BIDI ,华三百兆 SFP光模块,SFP-FE-LX-SM1550-BIDI ,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-FE-LX-SM1310-BIDI

    SFP-FE-LX-SM1310-BIDI

    917
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-FE-LX-SM1310-BIDI

    SFP-FE-LX-SM1310-BIDI,华三百兆 SFP光模块,H3C SFP-FE-LX-SM1310-BIDI,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-GE-LH70-SM1550-BIDI

    SFP-GE-LH70-SM1550-BIDI

    673
    • 设备品牌:华三(H3C)
    • 型号SKU: SFP-GE-LH70-SM1550-BIDI

    SFP-GE-LH70-SM1550-BIDI,华三1G SFP光模块,H3C SFP-GE-LH70-SM1550-BIDI,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-GE-LH70-SM1490-BIDI

    SFP-GE-LH70-SM1490-BIDI

    684
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-GE-LH70-SM1490-BIDI

    SFP-GE-LX-SM1310-BIDI,华三10G SFP光模块,H3CSFP-GE-LH40-SM1310-BIDI,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

loading…

已经是到最后一篇内容了！

最新商品

  • SFP-GE-T SFP-GE-(RJ45).

    SFP-GE-T SFP-GE-(RJ45).

    849
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-GE-T

    SFP-GE-T,华三10G SFP电口光模块,H3C SFP-GE-T,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-GE-PX20-D-SM1490-M SFP 1G Transceiver-(1490nm(Transmit)/1310nm(Recieve),20km,RSSI,SC/PC).

    SFP-GE-PX20-D-SM1490-M SFP 1G Transceiver-(1490nm(Transmit)/1310nm(Recieve),20km,RSSI,SC/PC).

    955
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-GE-PX20-D-SM1490-M

    SFP-GE-PX20-D-SM1490-M,华三1G SFP光模块,H3C SFP-GE-PX20-D-SM1490-M,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-FE-LX-SM1550-BIDI

    SFP-FE-LX-SM1550-BIDI

    890
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-FE-LX-SM1550-BIDI

    SFP-FE-LX-SM1550-BIDI ,华三百兆 SFP光模块,SFP-FE-LX-SM1550-BIDI ,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-FE-LX-SM1310-BIDI

    SFP-FE-LX-SM1310-BIDI

    917
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-FE-LX-SM1310-BIDI

    SFP-FE-LX-SM1310-BIDI,华三百兆 SFP光模块,H3C SFP-FE-LX-SM1310-BIDI,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-GE-LH70-SM1550-BIDI

    SFP-GE-LH70-SM1550-BIDI

    673
    • 设备品牌:华三(H3C)
    • 型号SKU: SFP-GE-LH70-SM1550-BIDI

    SFP-GE-LH70-SM1550-BIDI,华三1G SFP光模块,H3C SFP-GE-LH70-SM1550-BIDI,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-GE-LH70-SM1490-BIDI

    SFP-GE-LH70-SM1490-BIDI

    684
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-GE-LH70-SM1490-BIDI

    SFP-GE-LX-SM1310-BIDI,华三10G SFP光模块,H3CSFP-GE-LH40-SM1310-BIDI,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

loading…

已经是到最后一篇内容了！

促销商品

  • SFP-GE-T SFP-GE-(RJ45).

    SFP-GE-T SFP-GE-(RJ45).

    849
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-GE-T

    SFP-GE-T,华三10G SFP电口光模块,H3C SFP-GE-T,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-GE-PX20-D-SM1490-M SFP 1G Transceiver-(1490nm(Transmit)/1310nm(Recieve),20km,RSSI,SC/PC).

    SFP-GE-PX20-D-SM1490-M SFP 1G Transceiver-(1490nm(Transmit)/1310nm(Recieve),20km,RSSI,SC/PC).

    955
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-GE-PX20-D-SM1490-M

    SFP-GE-PX20-D-SM1490-M,华三1G SFP光模块,H3C SFP-GE-PX20-D-SM1490-M,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-FE-LX-SM1550-BIDI

    SFP-FE-LX-SM1550-BIDI

    890
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-FE-LX-SM1550-BIDI

    SFP-FE-LX-SM1550-BIDI ,华三百兆 SFP光模块,SFP-FE-LX-SM1550-BIDI ,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-FE-LX-SM1310-BIDI

    SFP-FE-LX-SM1310-BIDI

    917
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-FE-LX-SM1310-BIDI

    SFP-FE-LX-SM1310-BIDI,华三百兆 SFP光模块,H3C SFP-FE-LX-SM1310-BIDI,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-GE-LH70-SM1550-BIDI

    SFP-GE-LH70-SM1550-BIDI

    673
    • 设备品牌:华三(H3C)
    • 型号SKU: SFP-GE-LH70-SM1550-BIDI

    SFP-GE-LH70-SM1550-BIDI,华三1G SFP光模块,H3C SFP-GE-LH70-SM1550-BIDI,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

  • SFP-GE-LH70-SM1490-BIDI

    SFP-GE-LH70-SM1490-BIDI

    684
    • 设备品牌:华三(H3C)
    • 型号SKU:SFP-GE-LH70-SM1490-BIDI

    SFP-GE-LX-SM1310-BIDI,华三10G SFP光模块,H3CSFP-GE-LH40-SM1310-BIDI,Transceiver Modules,由交换机商城提供华三光缆线缆全线产品在线销售服务。

loading…

已经是到最后一篇内容了！

C9K-CMPCT-DESK-MNT= Under desk mount for compact switches

Mounting Under a Desk or a Shelf

Before you begin

Ensure you have the following items before starting the procedure.

  • Desk mount (C9K-CMPCT-DESK-MNT)
  • Three 8-18 Phillips pan-head screws
  • Two 10-32 Phillips pan-head screws
  • Screwdriver

Procedure

Step 1Use the desk mount to align the screw holes and also as a guide to make sure that you install the screws under the desk or shelf with proper clearance.
Step 2Use a 0.144-inch (3.7 mm) or a #27 drill bit to drill three holes, 1/2-inches (12.7 mm) deep on the desk or shelf.
Step 3Insert the screws in to the slots on the desk mount, and tighten them.Figure 8. Installing the Desk Mount Under a Desk or a Shelf
1Desk3Three 8-18 Phillips pan-head screws2Desk mount–
Step 4Place the switch on the mounting tray, slide it slightly forward so that the mounting tray hooks on both the sides engage with the switch.Figure 9. Aligning the Mounting Tray Hooks with the Switch
1Switch3Mounting tray2Mounting tray hook–Warning To prevent airflow restriction, allow clearance around the ventilation openings to be at least: 3 in. (7.6 cm) Statement 1076
Step 5Secure the switch to the desk mount using the two 10-32 Phillips pan-head screws provided.Figure 10. Mounting the Switch Under a Desk or Shelf
1Two 10-32 Phillips pan-head screws–
C9K-CMPCT-DESK-MNT= Under desk mount for compact switches - 思科配件（images 22）
Figure 11. The Switch in Installed Position
